3
EN
Connecting the water outlet hose
Connect the outlet hose (without bending it) to a drain
duct with a minimum diameter of 4 cm. Alternatively, rest
it over a sink or tub; the free end of the hose should not
remain immersed in water.
The special plastic elbow*
makes it easier to find the
best layout: fix the elbow to
the wall securely in order to
prevent the outlet hose from
moving and spilling the dirty
water.
The part of the hose marked
with the letter A should be
between 40 and 100 cm
above the ground (
see
figure
).
We advise against the use of hose extensions.
Electrical connection
Before inserting the plug into the electrical socket, make
sure that:
• the socket is earthed and complies with current
regulations;
• the socket can withstand the maximum load of the
appliance, which is indicated on the data plate
located on the inside of the door (
see Description of
the appliance
);
• the power supply voltage falls within the values
indicated on the data plate on the inside of the door;
• the socket is compatible with the plug of the
appliance. If this is not the case, ask an authorised
technician to replace the plug (
see Assistance
); do
not use extension cables or multiple sockets.
Once the appliance has been installed, the
power supply cable, the electrical plug and socket
should remain accessible.
If the power supply cable is damaged, it must
be replaced by the manufacturer or its Technical
Assistance Service in order to prevent all potential
hazards. (See Assistance)
The cable should not be bent or compressed.
The Company shall not be held responsible for
any incidents that occur if these regulations are not
observed.
Advice regarding the first wash cycle
After the appliance has been installed, immediately
before running the first wash cycle, completely fill the
salt dispenser with water and add approximately 2 kg of
salt (
see Rinse aid and refined salt
). The water may
overflow: this is normal and is not a cause for concern.
It is also normal that the LOW SALT* indicator light
continues to flash for a few cycles after the salt has been
loaded.
Anti-condensation strip*
After installing the dishwasher, open the door and stick
the adhesive transparent strip under the wooden shelf in
order to protect it from any condensation that may form.
Technical data
* Only available in selected models.
Dimensions
width 44.5 cm
height 82 cm
depth 57 cm
Capacity
9 standard place-settings
Water supply
pressure
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
4.3 psi – 145 psi
Power supply
voltage
See appliance data plate
Total absorbed
power
See appliance data plate
Fuse
See appliance data plate
This dishwasher conforms to
the following European
Community Directives:
-73/23/EEC dated 19/02/73
(Low Voltage) and subsequent
modifications
-89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent modifications
-97/17/EC (Labelling)
-2002/96/ CE (
Waste
Electrical and Electronic
Equipment WEEE)
A
