MSI MPG X299M GAMING EDGE AC [15/96] Specifications
![MSI MPG X299M GAMING EDGE AC [15/96] Specifications](/views2/1566228/page15/bgf.png)
15
Specifications
Specifications
CPU
y Supports Intel
®
Core™ X-Series Processor Family for
LGA2066 Socket*
* MPG X299M GAMING EDGE AC does not support Intel
®
Core™ i7-7740X and
i5-7640X processors.
Chipset Intel
®
X299 Chipset
Memory
y 4x DDR4 memory slots, support up to 64GB
y Quad channel memory architecture with the CPU that
supports up to 4-channels DDR4
X-series processor support DDR4 4200(OC)/ 4133(OC)/
4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/
3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3000(OC)/
2933(OC)/ 2800(OC)/ 2667/ 2400/ 2133 MHz*
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
* For the latest information about memory, please visit http://www.msi.com
Expansion Slots
y 3x PCIe 3.0 x16 slots
Support x16/ x16/ x4 mode with the 44-lane CPU.
Support x16/ x8/ x4 mode with the 28-lane CPU.
Multi-GPU
y Supports AMD
®
CrossFire
™
Technology
y Supports NVIDIA
®
SLI
™
Technology
LAN
1x Intel I219-V Gigabit LAN controller
1x Intel I211-AT Gigabit LAN controller
Wireless LAN &
Bluetooth
®
y Intel
®
Dual Band Wireless-AC 9260 module
The Wireless module is pre-install in the WIFI1 (M.2
Key-E) slot.
Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz,
5GHz) up to 1.73 Gbps speed.
Supports Dual Mode Bluetooth
®
2.1, 2.1+EDR, 3.0, 4.0,
BLE, 4.2, 5.0
Audio
y Realtek
®
ALC1220 Codec
y 7.1-Channel High Definition Audio
y Supports S/PDIF output
Continued on next page
