Onboard LEDs
LED Color Fan control mode
Red PWM mode
Green DC mode
Fan LED
This LED indicates the fan control mode.
CPU_FAN1 LED
JPWRLED1: LED power input
This connector is used by retailers to demonstrate onboard LED light effects.
JPWRLED1 - LED power input
