12
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
1. Quick-release chuck
2. Torque adjustment ring
3. Direction selector switch
4. Battery
5. Battery lock button
6. Switch
7. Lighting
8. Level vial
9. Charging station
10. Charger
11. LED
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY / SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Battery - 2 pcs
2. Charger - 1 pce
3. Charging station - 1 pce
4. Driver bits - 8 pcs
5. Bit holder - 1 pce
6. Drills - 6 pcs
7. Carrying case - 1 pce
PREPARATION FOR OPERATION
REMOVING AND INSERTING THE BATTERY
• Set the direction selector switch (3) in middle position.
• Push battery lock button (5) and slide out the battery (4) (g. A).
• Insert charged battery (4) into the handle holder, you should hear
when the battery lock button (5) snaps.
BATTERY CHARGING
Drill is supplied with partially charged battery. The battery should be
charged in ambient temperature between 4°C and 40°C. New battery,
or one that has not been used for a long time, will reach full efficiency
after approximately 3 to 5 charge/discharge cycles.
• Remove the battery (4) from the drill (g. A).
• Connect the charging station (9) to the charger (10).
• Connect the charger (10) to mains socket (230 V AC).
• Put the battery (4) inside the charging station (9) (g. B).
When the charger is connected to power supply, the LED (11) of the
charger (10) is lit. LED lighting scheme is described below.
• Diode on green – indicates voltage on the connector.
• Diode on red – charging is in progress (when battery is in the
charger).
• Diode on green again – the battery is fully charged.
• Diode o – damaged battery (when the system is connected to
mains network).
Once the battery has been charged, the diode (11) is lit until you will
disconnect the charger from mains network.
Batteries heat up strongly when charging. Do not operate just
after charging – wait for the battery to cool down to room
temperature. It will prevent battery damage.
SPINDLE BRAKE
Drill is equipped with electronic brake that stops the spindle
immediately after the switch button (6) is released. The brake ensures
precision when screwing or drilling and prevents free spindle rotation
after switching off.
PERPENDICULAR DRILLING / SCREWING
Vial (8) with double lines is used to set up 90° angle for drilling or
screwing in vertical surfaces.
OPERATION / SETTINGS
SWITCHING ON / SWITCHING OFF
Switching on – press the switch button (6).
Switching o – release the switch button (6).
Each time the switch button (6) is pressed, the LED diode (7) lights up
to illuminate the workplace.
ROTATIONAL SPEED CONTROL
Increase or reduce pressure on the switch button (6) to adjust drilling
or driving speed while operating. Speed adjustment allows for a soft
start, which prevents dill slipping when drilling holes in gypsum or
glaze, and allows for operation control when screwing in and out.
OVERLOAD CLUTCH
Set the torque adjustment ring (2) in appropriate position to
permanently set overload clutch to defined torque value. When the
set torque is reached, overload clutch disconnects automatically. It
prevents screwing screws too deep or damaging the drill.
TORQUE ADJUSTMENT
• Different screws and materials require different torque to be
applied.
• The bigger the number corresponding to given position, the bigger
is the torque (g. C).
• Set the torque adjustment ring (2) to appropriate torque value.
• Always start operation with low torque.
• Increase the torque gradually until obtaining desired results.
• Use higher settings to unscrew screws.
• When drilling, choose setting marked with the drill symbol. The
torque is the greatest with this setting.
