galletti.com VM66000387-C
Air chillers and heat pumps MPI DC
Large operating range and energy
efficiency under every condition
The MPI DC series consists of 6 heat pump models and
5 cold only models and is intended mainly for residential
or light commercial applications. Due to the control
managed by a software program developed by Galletti,
the MPI DC series’ adjustment logic makes it possible to
adjust the water delivery temperature to the set value and
to control the compressor so that the power generated
by the machine is adjusted to the thermal load required
by the system. This represents a strategic feature in the
limiting of energy consumption, because the effective
thermal load of an air conditioning system is less than
60% of the nominal load most of the time.
The BLDC technology upon which is based the
compressor’s electric motor guarantees the ability to
change the rotation speed in a frequency range between
30 and 120 Hz, thereby reducing at the same time the
power consumption and thus maintaining a high level of
efficiency in the operation at partial load and improved
isentropic efficiency. These units’ large operating range,
which is also achieved due to the variable flow water
circulator they are equipped with as a standard feature,
guarantees operation with air temperatures from -15
°C up to 52 °C, while in heating mode it is possible to
produce hot water up to 58 °C. This allows their use as a
single generator in addition to summer air conditioning,
even in medium-temperature heating systems and for the
production of DHW. Furthermore, the innovative Smart
Defrost System guarantees that defrosting always occurs
in the most efficient manner even under the most extreme
environmental conditions.
Outdoor monobloc unit with BLDC compressor
MPI DC 8 - 29 kW
PLUS
Twin-rotary or scroll compressor driven by an
electronic control BLDC motor
Electronically controlled electric expansion valve
Modulating hydraulic pump with stainless steel
impeller
Incorporable inertial tank
Access to the tax incentives provided for energy
retrotting
MPI DC can be the only heat
generator in low-power
systems due to its large
operating range that includes
both low winter temperatures
and high summer
temperatures.
R-410A
BLDC scroll
compressor
BLDC rotary
compressor
R-410A
refrigerant
Cooling only Cooling /
Heating
Monobloc
unit
Axial fans
