147
galletti.com VM66000387-C
Air chillers and heat pumps - MPI DC
MPI DC 8 - 29 kW
ACCESSORIES
Version
Fields
1 2 3 4 5 6 7 8 9 10 11 12 13
MPIDC014H0AC A 2 0 0 E P 3 0 2 0 G 0 2
CONFIGURATION
MAIN COMPONENTS
Structure
Hydraulic kit DHW kit
Compressor Heat exchanger Electronically controlled
electric expansion valve
It is constructed of galvanized
and painted sheet metal that
is resistant to corrosive agents.
Compressor compartment
closed and accessible from
three sides due to easily
removable panels, available
also with internal coating of
soundproofing material.
Variable flow centrifugal
circulator with stainless steel
impeller. An expansion vessel
and the automatic filling tap
are also included.
An inertial buffer tank built into
the structure is available as an
optional accessory.
A system that makes it possible to transform the MPI DC heat pumps into
multi-purpose units that are able not only to meet the requirements of
the air conditioning system, but also to produce domestic hot water as
a priority by means of the Galletti TP or TN series thermal storage tanks.
It is comprised of a microprocessor control unit with LCD display and
a 3-way motorized valve. Also, anti-Legionnaire’s disease cycles can be
activated by means of a heating element.
Hermetic twin-rotary or
scroll compressor driven by
a permanent magnet BLDC
motor and controlled by a
trapezoidal wave inverter. It is
attached to the base by means
of rubber dampers to reduce
the transmission of vibrations.
Finned heat exchanger
constructed with copper
pipes mechanically attached
to aluminum fins, carefully
designed to minimize the
defrosting phases and optimize
heat exchange efficiency in
every operating phase.
Key component for the proper
functioning of the unit. The PID
control algorithm allows it to
quickly adapt to all operating
conditions and to keep the
cooling cycle stable.
The models are completely configurable by selecting the
version and the options. To the right is shown an example
of configuration.
Cooling only versions
MPIDC…CMAC Water chiller 230V - 1 - 50 Hz
MPIDC…C0AC Water chiller 400V - 3N - 50 Hz
Versions with reversible heat pump
MPIDC…HMAC Air/water heat pump 230V - 1 - 50 Hz
MPIDC…H0AC Air/water heat pump 400V - 3N - 50 Hz
To verify the compatibility of the options, use the selection software or the price list.
AVAILABLE VERSIONS
CONFIGURATION OPTIONS
1 - EXPANSION VALVE
A
Electronic 230V
2 - PUMP USER SIDE AND ACCESSORIES
1
1 Modulating standard pump, system side
2
1 EC pump, system side
3 - BUFFER TANK
0
Absent
S
Present, system side
4 - DESUPERHEATER
0
Absent
5 - FANS
C
Standard with condensation control
E
BLDC with electronic control
6 - ANTIFREEZE KIT
0
Absent
E
Base (plate exchangers only)
P
Additional protection for 1 pump
S
Additional protection for 1 pump and tank
7 - SOUND INSULATION
0
Absent
1
Compressor compartment soundproofing
2
Compressor silencing housings
3
Opt 1 + Opt 2
8 - COOLING ACCESSORIES
0
None
M
Refrigerant pressure gauges
9 - REMOTE CONTROL / COMMUNICATION
0
Absent
2
RS485 (Carel / Modbus)
S
Simplified remote control
X
Advanced remote control (PCOXS)
10 -SPECIAL HEAT EXCHANGERS
0
Standard
R
Copper / copper
C
Cataphoresis
B
Fins pre-coated with epoxy paint
I
Hydrophilic
11 - CONDENSER PROTECTIVE GRILLE
0
Absent
G
Present
12 - COMPRESSOR OPTIONS
0
Absent
4
Exchanger heating cable (Heat Pump only)
13 - Microprocessor control
2
pCOXS controller
Base rubber vibration dumpers
Base spring vibration dumpers
Simplified remote control
MYCHILLER BASE (RS485 is a mandatory accessory)
MYCHILLER PLUS (RS485 is a mandatory accessory)
