LCE
RG66004766_rev.05
45
Cooling mode: outdoor air temperature 35°C, water temperature 12°C / 7°C
Sound power measured according to standards ISO 3741 - ISO 3744 and EN 29614-1
Sound pressure measured at a distance of 10 m and a height of 1.5 m above the ground in a clear field.
Approx, capacity (kW) 45 50 60 70 80 120
Efficiency Pack 22222124124124
LCE,,,CQ 042 052 062 072 082 091 092 094 101 102 104 121 122 124
Power supply V-ph-Hz
Cooling capacity kW 48 52,2 63,3 69,3 76,5 92,8 92,2 94,4 103,5 103,5 102,3 123,6 123,6 125,7
Total power input kW 16,2 20,8 24,8 27,7 31,7 32 36,2 32,3 38,4 43,3 37,1 454 47,1 45,1
Rated current input A 27,68 35,11 42,24 46,89 53,34 54,74 61,4 55,25 64,92 72,88 62,84 73,45 76,84 76,59
EER 2,96 2,51 2,56 2,5 2,42 2,9 2,6 2,92 2,7 2,39 2,76 2,75 2,62 2,79
ESEER 4,06 3,96 3,89 3,93 3,78 3,45 3,9 3,9 3,4 3,75 3,85 3,88 4,09 4,09
Maximum current input A 41 44 51 55 66 77 77,0 81 86 86 87 95 95 96
Starting current A 159 162 185 183 191 246 246,0 194 254 254 198 295 295 220
No, of scroll compressors / circuits 2 / 1 2 / 1 2 / 1 2 / 1 2 / 1 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2
No, of axial fans 44666888888666
Air flow rate m
3
/h 15.398 15.398 21.955 21.955 21.955 29.393 29.393 29.393 29.393 29.393 29.393 35.930 35.930 35.930
Water flow rate l/h 8.261 8.983 10.956 12.027 13.313 15.986 15.986 16.213 17.778 17.778 17.582 21.259 21.259 21.623
Pressure drop, water side kPa 26 44,12 47 35 43 31 32,0 32 39 39 38 39 39 40
Available head, standard pump kPa 157 149 125 131 117 129 129 128 118 118 119 109 109 106
Buffer tank dm
3
200 200 220 220 220 340 340 340 340 340 340 600 600 600
Expansion tank dm
3
12 12 12 12 12 12 12 12 12 12 12 24 24 24
Plumbing connections " 2 2 2 2 2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 3 3 3
Height mm 1735 1735 1735 1735 1735 1735 1735 1679 1735 1735 1679 1847 1847 1847
Length mm 2090 2090 2442 2442 2442 3190 3190 3540 3190 3190 3540 3538 3538 3538
Depth mm 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1653 1653 1653
Sound power level dB(A) 67,0 72,0 73,0 73,0 73,0 70,0 74,0 70,0 70,0 74,0 70,0 69,0 73,0 69,0
Sound pressure level dB(A) 39,0 44,0 45,0 45,0 45,0 42,0 46,0 42,0 42,0 46,0 42,0 41,0 45,0 41,0
Base unit operating weight kg 525 525 630 635 700 905 905 980 915 915 980 1260 1260 1275
Unit with pump and full tank operating weight kg 862 862 982 987 1067 1426 1426 1557 1436 1436 1557 2040 2040 2055
400-3-50
100
Rated technical data of LCE water chillers, QUIET (super low noise) version
90
Approx, capacity (kW) 170 190 210 240 270
290 320
Efficiency Pack 1241 2444 4 4 4
44
LCE,,,CQ 141 142 144 161 162 164
-
194 214 244 274 294 324
Power supply V-ph-Hz
Cooling capacity kW 135,5 137,7 137,7 151,5 154,7 150,2 - 186,7 208,8 236,9 272 296,1 214,2
Total power input kW 51,2 52,6 50,8 61,9 64 59,4 - 100,9 91,2 101,7 113,9 123,9 132
Rated current input A 83,35 85,68 82,76 100,58 103,98 96,53 - 163,1 147,61 164,37 183,42 199,56 212,47
EER 2,65 2,62 2,71 2,45 2,42 2,53 - 1,85 2,29 2,33 2,39 2,39 2,38
ESEER 3,93 4,01 4,1 3,61 3,79 3,75 - 3,84 3,84 3,89 3,94 3,91 4,05
Maximum current input A 106 106 105 120 120 126 - 148 167 190 215 229 242
Starting current A 306 306 222 317 317 241 - 307 318 382 398 494 472
No, of scroll compressors / circuits 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 - 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2
No, of axial fans 666666-666888
Air flow rate m
3
/h 35.930 35.930 35.930 35.930 35.930 35.930 - 35.930 40.953 40.953 69.835 69.835 69.835
Water flow rate l/h 23.303 23.303 23.667 26.051 26.051 25.816 - 28.282 33.135 36.054 44.837 47.938 50.535
Pressure drop, water side kPa 47 47 48 40 41 40 - 39 39 42 38 44 48
Available head, standard pump kPa 153 153 151 151 151 152 - 161 171 193 177 164 153
Buffer tank dm
3
600 600 600 600 600 600 - 600 600 600 600 600 600
Expansion tank dm
3
24 24 24 24 24 24 - 24 24 24 24 24 24
Plumbing connections 3 3 3 3 3 3 - 3 4 4 4 4 4
Height mm 1847 1847 1847 1847 1847 1847 - 1847 2247 2247 2330 2330 2330
Length mm 3538 3538 3538 3538 3538 3538 - 3538 3538 3538 4206 4206 4206
Depth mm 1653 1653 1653 1653 1653 1653 - 1653 1653 1653 1653 1653 1653
Sound power level dB(A) 69,0 73,0 69,0 69,0 73,0 69,0 - 73,0 73,0 73,0 74,0 74,0 74,0
Sound pressure level dB(A) 41,0 45,0 41,0 41,0 45,0 41,0 - 45,0 45,0 45,0 46,0 46,0 46,0
Base unit operating weight kg 1310 1310 1290 1330 1330 1440 - 1460 1510 1620 1880 1912 1947
Unit with pump and full tank operating weight kg 2090 2090 2070 2110 2110 2220 - 2276 2326 2469 2894 2926 2961
Rated technical data of LCE water chillers, QUIET (super low noise) version
140 160
400-3-50
