LCE
RG66004766_rev.05
44
Cooling mode: outdoor air temperature 35°C, water temperature 12°C / 7°C
Sound power measured according to standards ISO 3741 - ISO 3744 and EN 29614-1
Sound pressure measured at a distance of 10 m and a height of 1.5 m above the ground in a clear field.
Approx, capacity (kW) 45 50 60 70 80 120
Efficiency Pack 2222 2124 1 2 4 1 24
LCE,,,CL 042 052 062 072 082 091 092 094 101 102 104 121 122 124
Power supply V-ph-Hz
Cooling capacity kW 48 52,2 63,6 69,3 76,5 92,8 92,2 94,4 103,5 103,5 101,8 125 123,6 127,5
Total power input kW 16,2 20,2 24,8 27,7 31,7 32 36,2 32,3 38,4 43,3 37,56 44,5 47,1 44,2
Rated current input A 27,68 34,16 42,24 46,89 53,34 54,74 61,4 55,25 64,92 72,88 70,2 72,65 76,82 72,25
EER 2,96 2,58 2,56 2,5 2,42 2,9 2,6 2,92 2,7 2,39 2,71 2,81 2,62 2,88
ESEER 4,06 3,96 3,89 3,93 3,78 3,45 3,9 3,9 3,4 3,75 3,85 3,88 4,09 4,09
Maximum current input A 41 44 51 55 66 77 77,0 81 86 86 87 95 95 96
Starting current A 159 162 185 183 191 246 246 194 254 254 198 295 295 220
No, of scroll compressors / circuits 2 / 1 2 / 1 2 / 1 2 / 1 2 / 1 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2
No, of axial fans 4466 6888 8 8 8 6 66
Air flow rate m
3
/h 15398 15398 21955 21955 21955 29393 29393 29393 29393 29393 29393 43434 43434 43434
Water flow rate l/h 8261 8983 10956 12027 13313 15986 15986,0 16213 17778 17778 17582 21518 21518 21906
Pressure drop, water side kPa26314735433132,032393938404041
Available head, standard pump kPa 157 149 125 131 117 129 129,0 128 118 118 119 107 107 105
Buffer tank dm
3
200 200 220 220 220 340 340 340 340 340 340 600 600 600
Expansion tank dm
3
12 12 12 12 12 12 12 12 12 12 12 24 24 24
Plumbing connections " 2 2 2 2 2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 2 1/2 3 3 3
Height mm 1735 1735 1735 1735 1735 1735 1735 1679 1735 1735 1679 1847 1847 1847
Length mm 2090 2090 2442 2442 2442 3190 3190 3540 3190 3190 3540 3538 3538 3538
Depth mm 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1183 1653 1653 1653
Sound power level dB(A) 70,0 74,0 76,0 76,0 76,0 73,0 77,0 73,0 73,0 77,0 73,0 77,0 81,0 77,0
Sound pressure level dB(A) 42,0 46,0 48,0 48,0 48,0 45,0 49,0 45,0 45,0 49,0 49,0 49,0 53,0 49,0
Base unit operating weight kg 525 525 630 635 700 905 905 980 915 915 980 1260 1260 1275
Unit with pump and full tank operating weight kg 862 862 982 987 1067 1426 1426 1557 1436 1436 1557 2040 2040 2055
Rated technical data of LCE water chillers, LOW NOISE version
90 100
400-3-50
Approx, capacity (kW) 170 190 210 240 270
290 320 360
Efficiency Pack 1241 2444 4 4 4
444
LCE,,,CL 141 142 144 161 162 164
ND
194 214 244 274 294 324 364
Power supply V-ph-Hz
Cooling capacity kW 137,4 137,7 139,7 155,4 154,7 153,7 - 186,9 208,9 237 271,9 296,1 214,3 341,1
Total power input kW 50,3 52,6 49,6 60,2 64 57,7 - 77,3 91,1 101,6 113,9 123,9 131,9 143,6
Rated current input A 81,98 85,67 80,89 97,85 96,2 93,85 - 125,26 147,47 156,55 172,95 199,25 212,09 230,88
EER 2,73 2,62 2,82 2,58 2,42 2,66 - 2,42 2,29 2,33 2,39 2,39 2,38 2,37
ESEER 3,93 4,01 4,1 3,61 3,79 3,75 - 3,84 3,84 3,89 3,94 3,91 4,05 4,18
Maximum current input A 106 106 105 120 120 126 - 148 167 190 215 229 242 300
Starting current A 306 306 222 371 371 241 - 307 318 382 398 494 472 497
No, of scroll compressors / circuits 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 - 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2
No, of axial fans 6666 66-6 6 6 8 8 88
Air flow rate m
3
/h 43434 43434 43434 40235 40235 40235 - 55808 63261 63261 87186 81687 81687 81687
Water flow rate l/h 23655 23655 24043 26719 26719 26434 - 31172 36451 36615 45628 49438 52350 58337
Pressure drop, water side kPa 48 48 50 43 43 42 - 47 51 50 39 46 52 38
Available head, standard pump kPa 151 151 148 147 147 148 - 139 143 177 174 158 145 142
Buffer tank dm
3
600 600 600 600 600 600 - 600 600 600 600 600 600 600
Expansion tank dm
3
24 24 24 24 24 24 - 24 24 24 24 24 24 24
Plumbing connections " 3 3 3 3 3 3 - 3 4 4 4 4 4 4
Height mm 1847 1847 1847 1847 1847 1847 - 1847 2247 2247 2330 2330 2330 2330
Length mm 3538 3538 3538 3538 3538 3538 - 3538 3538 3538 4206 4206 4206 4206
Depth mm 1653 1653 1653 1653 1653 1653 - 1653 1653 1653 1653 1653 1653 1653
Sound power level dB(A) 77,0 81,0 77,0 77,0 81,0 77,0 - 81,0 81,0 82,0 83,0 83,0 83,0 79,0
Sound pressure level dB(A) 49,0 53,0 49,0 49,0 53,0 49,0 - 53,0 53,0 54,0 55,0 55,0 55,0 51,0
Base unit operating weight kg 1310 1310 1290 1330 1330 1440 - 1460 1510 1620 1880 1912 1947 1947
Unit with pump and full tank operating weight kg 2090 2090 2070 2110 2110 2220 - 2276 2326 2469 2894 2926 2961 2961
160
Rated technical data of LCE water chillers, LOW NOISE version
140
400-3-50
