Cooling mode: outdoor air temperature 35°C, water temperature 12°C / 7°C
Heating mode: outdoor air temperature 7°C dry bulb and 6.2°C wet bulb, water temperature 40°C/45°C
Sound power measured according to standards ISO 3741 - ISO 3744 and EN 29614-1
Sound pressure measured at a distance of 10 m and a height of 1.5 m above the ground in a clear field.
Approx, capacity (kW) 170 190 210 240 270
290 320
Efficiency Pack 1241244 4 4 44
44
LCE…HL 141 142 144 161 162 164
ND
194 214 244 274 294 324
Power supply V-ph-Hz
Cooling capacity kW 137,4 137,7 139,7 155,4 155,7 153,7 - 180,8 211,9 230 265 287,1 304,2
Total power input in cooling mode kW 50,3 58,9 49,6 60,2 65,8 57,7 - 77,8 86,6 103,1 114,8 125,5 134,6
Rated current input A 81,98 95,69 80,89 97,85 106,84 93,85 - 126,01 140,25 166,7 184,71 201,78 216,44
EER 2,73 2,34 2,82 2,58 2,37 2,66 - 2,33 2,45 2,23 2,31 2,29 2,26
ESEER 3,93 4,01 4,1 3,61 3,79 3,75 - 3,84 3,84 3,94 3,91 4,05 4,18
Heating capacity kW 155,3 153,1 152,2 178,9 178,1 174,8 - 210,9 233,8 268,5 304,7 326,5 347,2
Total power input in heating mode kW 48 47,5 47,6 56,2 55,2 55,4 - 64,9 72,7 84,6 95,6 103,6 111,9
Rated current input A 78,35 77,54 77,57 91,42 82,02 90,14 - 105,42 117,89 136,92 153,79 166,69 179,98
COP 3,23 3,22 3,2 3,18 3,23 3,16 - 3,25 3,22 3,19 3,19 3,158 3,1
Maximum current input A 106 106 105 120 120 126 - 148 167 190 215 229 242
Starting current A 306 306 222 371 371 241 - 307 318 382 398 464 472
No, of scroll compressors / circuits 2 / 2 2 / 1 4 / 2 2 / 2 2 / 1 4 / 2 - 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2 4 / 2
No, of axial fans 666666 - 6 6 6888
Air flow rate m
3
/h 43434 43434 43434 40235 40235 40235 - 55808 63261 63261 87186 81687 81687
Water flow rate (cooling) l/h 23655 23655 24043 26719 26719 26434 - 31172 36451 36615 45628 49438 52350
Pressure drop, water side (cooling) kPa 48 49 50 43 43 43 - 47 51 39 46 52 52
Available head, standard pump (cooling) kPa 151 151 148 147 147 148 - 139 143 177 174 158 145
Buffer tank dm
3
600 600 600 600 600 600 - 600 600 600 600 600 600
Expansion tank dm
3
24 24 24 24 24 24 - 24 24 24 24 24 24
Plumbing connections 3 3 3 3 3 3 - 3 4 4 4 4 4
Height mm 1847 1847 1847 1847 1847 1847 - 1847 2247 2247 2330 2330 2330
Length mm 3538 3538 3538 3538 3538 3538 - 3538 3538 3538 4206 4206 4206
Depth mm 1653 1653 1653 1653 1653 1653 - 1653 1653 1653 1653 1653 1653
Sound power level dB(A) 77,0 92,0 77,0 77,0 81,0 77,0 - 81,0 81,0 82,0 83,0 83,0 83,0
Sound pressure level dB(A) 49,0 64,0 49,0 49,0 53,0 49,0 - 53,0 53,0 54,0 55,0 55,0 55,0
Base unit operating weight kg 1310 1310 1290 1330 1330 1440 - 1460 1510 1620 1880 1912 1947
Unit with pump and full tank operating weight kg 2090 2090 2070 2110 2110 2220 - 2276 2326 2469 2894 2926 2961
400-3-50
Rated technical data of LCE heat pumps, LOW NOISE version
140 160
