CG Drives & Automation, 01-6142-01r0 Introduction 7
1.4 Type code number
Fig. 1 gives an example of the type code numbering used on
all AC drives
. With this code number the exact type of the
drive can be determined. This identification will be required
for type specific information when mounting and installing.
The code number is located on the product label, on the
unit.
Fig. 1 Type code number
Type code
FLD48-017-20CE–––AVNNNNAN––
Position No
1 2 3 4 5 6 7 8 9 10111213141516171819
Position
for 003-074
Position
for 090-293
Configuration
11AC drive type FLD
2 2 Supply voltage
48=480 V mains
52=525 V mains
69=690 V mains
3 3 Rated current (A) continuous
-003=2.5 A
-
-293=293 A
44Protection class
20=IP20
21=IP21
54=IP54
5 5 Control panel
–=Blank panel
C=Standard panel
6 6 EMC option
E=Standard EMC (Category C3)
F=Extended EMC (Category C2)
I=IT-Net
7 7 Brake chopper option
–=No chopper
B=Chopper built in
D=DC+/- interface
8 8 Stand-by power supply option
–=No SBS
S=SBS included
-9
Safe stop option
(Only valid for 090-
293)
–=No safe stop
T=Safe stop incl.
910Brand label A=Standard
10 - Painted AC drive A=Standard paint
11 11 Coated boards V=Coated boards, standard
12 12 Option position 1 N=No option
P=PTC/PT100 (max. 1)
I=Extended I/O (max. 3)
S=Safe Stop (only 003-074/IP54) (max. 1)
U= RTC- Real time clock (max. 1)
13 13 Option position 2
14 14 Option position 3
