Position Code Description
18 Impeller material
G JL 1040/A48CL35
C 1.4408/A743CF8M
B CC480K-GS/B30 C90700
19 Design
- Standard
X Special design BT3D, BT3
20 Casing cover
A Conical seal chamber
21 Seal variants
B Dead-end arrangement (for Etaline SYT only)
E External circulation
V Conical seal chamber with vent
A Conical seal chamber
22-23 Seal code
06 U3BEGG (WE 25, 35)
07 Q1Q1EGG
08 AQ1VGG
09 U3U3VGG
10 Q1Q1X4GG
11 BQ1EGG
22 AQ1EGG (WE 55)
24 Scope of supply
A Pump only (Fig. 0)
D Pump, baseplate, coupling, coupling guard, motor
25 Shaft unit
2 Shaft unit 25
3 Shaft unit 35
5 Shaft unit 55
26-29 Motor rating
0002 0.2 KW
0003 0.3 KW
0005 0.5 KW
0007 0.7 KW
0011 1.1 kW
0015 1.5 kW
0022 2.2 kW
0030 3.0 KW
0040 4.0 KW
0055 5.5 kW
0075 7.5 kW
0110 11.0 KW
0150 15.0 KW
0185 18.5 kW
0220 22.0 KW
0300 30.0 KW
0370 37.0 KW
0450 45.0 KW
0550 55.0 KW
30 Number of poles
2 2-pole
4 4-pole
31-32 Explosion protection
Ex Explosion-proof motor
-- Without explosion-proof motor
33 Product generation
B Product generation Etaline / Etaline SYT GP
34-36 Motor manufacturer
KSB KSB
SIE Siemens
LOH Loher
HAL Halter
37-39 Efficiency class
IE1 IE1
Heating / Air-conditioning / Ventilation
In-line Pumps
88
