High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 93
The definition table of multifunctional analog output and pulse output is as follows:
Function
setup
Output signal
selection
Definition of analog output range
Definition of pulse output range
48
Output
frequency
Maximum frequency P0.11
corresponds to 10V/20mA.
Maximum frequency P0.11
corresponds to P7.10.
49
Setup
frequency
Maximum frequency P0.11
corresponds to 10V/20mA.
Maximum frequency P0.11
corresponds to P7.10
50 Output current
Two times rated current of inverter
corresponds to 10V/20mA.
Two times rated current of inverter
corresponds to P7.10
51 Motor current
Two times rated current of motor
corresponds to10V/20mA
Two times rated current of motor
corresponds to P7.10.
52 Output torque
Two times rated torque of motor
corresponds to 10V/20mA.
Two times rated torque of motor
corresponds to P7.10
53 Output voltage
Two times maximum output voltage
P0.12 corresponds to 10V/20mA.
Two times maximum output voltage
P0.12 corresponds to P7.10
54 Bus voltage 1000V corresponds to 10V/20mA 1000V corresponds to P7.10.
55 AI1
10V corresponds to 10V/20mA;
20mA corresponds to 5V/10mA.
10V corresponds to P7.10; 20mA
corresponds to 50% of P7.10.
56 AI2 The same as AI1 The same as AI1.
57 AI3
-10V ~ 10V corresponds to 0 ~
10V/20mA.
-10V ~ 10V corresponds to 0 ~
P7.10.
58 DI
Maximum input pulse frequency
P5.10 corresponds to 10V/20mA.
Maximum input pulse frequency
P5.10 corresponds to P7.10
59 Output power
2 times rated output power of motor
corresponds to 10V/20mA.
2 times rated output power of motor
corresponds to P7.10.
60
Host computer
percentage
10000 corresponds to10V/20mA. 10000 correspond to P7.10.
61
Heatsink
temperature
0 to 100 corresponds to 0 to ℃
10V/20mA
100 corresponds to P7.10℃
62
Output
frequency 2
Maximum frequency P0.11
corresponds to 10V/20mA
Maximum frequency P0.11
corresponds to 10V/20mA
63~71
Reserved
Note: Output frequency indicate the output frequency of inverter, Output frequency 2 indicate the frequency
calculate by motor rotate speed.
P7.05 AO1 gain
0.0 ~ 200.0 %(100.0%)
P7.06 AO1 bias
0.0 ~ 200.0 %(0.0%)
P7.07 AO2 gain
0.0 ~ 200.0 %(100.0%)
P7.08 AO2 bias
0.0 ~ 200.0 %(0.0%)
P7.09 Selection of positive and negative gain and bias
0000~1111(0000)
