High Performance Vector Control/Torque Control Inverter User Manual
Chapter 6 Parameter Description 77
In addition to the above acceleration time 0 (P0.08) and deceleration time 0 (P0.09) , three groups of
acceleration/deceleration time (acceleration/deceleration time 1, acceleration/deceleration time 2,
acceleration/deceleration time 3) can be defined. Different acceleration/deceleration time can be
selected in different terminal status by defining the multi-functional terminal X (acceleration/deceleration
time selection function: 13~14). The meaning of the three groups of acceleration/deceleration time is the
same as P0.08 and P0.09.
It can be used as the process open loop frequency reference or analog feedback close loop digital
reference. Different digital voltage reference is selected in different terminal status by defining the
multi-functional terminal X (multi-section analog input terminals 1~3). ON means that the terminal is
enabled, OFF means that the terminal is disabled.
Setting frequency Multi-stage
digital voltage
input terminal 3
Multi-stage
digital voltage
input terminal 2
Multi-stage
digital voltage
input terminal 1
Process open loop
control
Process PID close
loop control
OFF OFF OFF
Open loop frequency
P0.05
Close loop digital
voltage reference
OFF OFF ON Multi-section digital
voltage reference 1
Multi-section digital
voltage reference 1
OFF ON OFF Multi-section digital
voltage reference 2
Multi-section digital
voltage reference 2
OFF ON ON Multi-section digital
voltage reference 3
Multi-section digital
voltage reference 3
ON OFF OFF Multi-section digital
voltage reference 4
Multi-section digital
voltage reference 4
ON OFF ON Multi-section digital
voltage reference 5
Multi-section digital
voltage reference 5
ON ON OFF Multi-section digital
voltage reference 6
Multi-section digital
voltage reference 6
ON ON ON Multi-section digital
voltage reference 7
Multi-section digital
voltage reference 7
Note: Upon process open loop operation, if the input terminal function sets the multi-section digital
voltage and multi-section frequency simultaneously, the multi-section frequency will have priority. Upon
P4.15
Multi-section digital voltage reference 1 0.00~10.00 V(1.00V)
P4.16 Multi-section digital voltage reference2
0.00~10.00 V(2.00V)
P4.17 Multi-section digital voltage reference3
0.00~10.00 V(3.00V)
P4.18 Multi-section digital voltage reference4
0.00~10.00 V(5.00V)
P4.19 Multi-section digital voltage reference5
0.00~10.00 V(6.00V)
P4.20 Multi-section digital voltage reference6
0.00~10.00 V(8.00V)
P4.21 Multi-section digital voltage reference7 0.00~10.00 V(10.00V)
