+7(495) 797-3311www.qtech.ru
Москва, Новозаводская ул., 18, стр. 1
52
Ctrl field
20
TCP destination interface
48
org code field
21
Sequence number
50
Encapsulated data type
24
Confirm field
54
IP version number
26
Length of IP head and reserved
byte
58
TOS field
27
Reserved byte and flags byte
59
Length of IP packet
28
Window Size field
60
ID number
30
Others
62
Flags field
32
In user-defined ACL, user can using rule mask and offset value to extract any byte of the first
64 bytes from data frame to compare with user-defined rule to filtrate matched data frame to
make corresponded handling. User-defined rule can be some fixed attribution of data, such as:
user can define rule to be «06» , rule mask to be «FF» , offset value to be 35. rule mask and
offset value can extract TCP protocol byte content of received data frame to compare with rule
to match all TCP packet.
(1) Define user-defined ACL based on number ID
User-defined ACL based on number ID is using number to be ID of user-defined ACL. Use
following command to define user-defined ACL based on number ID.
Use following command to define user-defined ACL with number ID.
Configure it in global configuration mode.
Define user-defined ACL with number ID.
access-list access-list-number4 { permit | deny } { rule-string rule-mask offset }&<1-20> [
ingress interface interface-num ] [ egress interface interface-num | cpu ] [ time-range time-
range-name ]
Define the matching order of ACL:
access-list access-list-number match-order { config | auto }
Delete all the subitems or one subitem in one ACL with number ID or name ID or all ACLs.
no access-list { all | { access-list-number | name access-list-name } [ subitem ] }
Use access-list command repeatedly to define more rules for the same ACL.
The number ID of user-defined ACL is in the range of 300 to 399. Concrete parameter
meaning refers to corresponded command line.
(2) Define standard ACL with name ID.
Standard ACL with name ID is using name ID to identify standard ACL.
Instruction:
Defining user-defined ACL with name ID should enter specified configuration mode: use
access-list user in global configuration mode which can specify matching order of ACL. Use
exit command to be back from this mode.
Use following commands to define user-defined ACL with name ID. Configure it in
corresponded mode.
Enter user-defined ACL with name ID configuration mode (global configuration mode)
access-list user name [ match-order { config | auto } ]
Defining user-defined ACL rule (user-defined ACL with name ID configuration mode)
{ permit | deny } { rule-string rule-mask offset }&<1-20> [ ingress interface interface-num ] [
egress interface interface-num | cpu ] [ time-range time-range-name ]
