77
Chapter 12 SYSLOG CONFIGIRATION
12.1 Brief introduction of Syslog
Syslog is system information center, which handles and outputs information uniformly.
Other modules send the information to be outputted to Syslog, and Syslog confirms the form of
the outputting of the information according to user’s configuration, and outputs the information
to specified displaying devices according to the information switch and filtration rules of all
outputting directions.
Because of Syslog, information producer—all modules of outputting information need not care
where the information should be send at last, console, telnet terminal or logging host (Syslog
server). They only need send information to Syslog. The information consumer—console,
Telnet terminal, logging buffer, logging host and SNMP Agent can choose the information they
need and drop what they needn’t for suitable filtration rules.
Syslog information level reference:
severe level
Description
corresponded explanation
0: emergencies
the most emergent error
need reboot
1: alerts
need correct immediately
self-loop, hardware error
2: critical
key error
memory, resources distribution
error
3: errors
non-key errors need cautions
general error; invalid parameter
which is hard to restore
4: warnings
Warning for some error which
may exist
alarm; losing packet which is not
important; disconnect with the
exterior server
5: notifications
information needs cautions
Trap backup outputting
6: informational
general prompt information
command line operation log; set
operation for MIB node
7: debugging
debug information
debugging outputting; process,
data of service protocol
12.2 Syslog Configiration
Syslog configuration command includes:
Enable/disable Syslog
Syslog sequence number configuration
Syslog time stamps configuration
Syslog logging language configuration
Syslog terminal outputting configuration
Syslog logging buffered outputting configuration
Syslog Flash storage outputting configuration
Syslog logging host outputting configuration
Syslog SNMP Agent outputting configuration
