QSW-6200 Series Switch Hardware Installation and Reference Guide 10
www.qtech.ru
Blinking green
The port is receiving or transmitting traffic at 1/10
Gbps.
GE SFP port status
LED
25F-28F
Off
The port is not connected.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
1000 Mbps.
Solid yellow
The port is connected at 100 Mbps.
Blinking yellow
The port is receiving or transmitting traffic at 100
Mbps.
10/100/1000Base-T
auto-sensing
Ethernet port status
LED
1-28
Off
The port is not connected.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting traffic at
1000 Mbps.
Solid yellow
The port is connected at 10/100 Mbps.
Blinking yellow
The port is receiving or transmitting traffic at
10/100 Mbps.
1.2 QSW-6200-52T
Technical Specifications
Model
QSW-6200-52T
Expansion Module
Slot
2 slots
Power Module
Slot
2 slots
AC input
Rated voltage: 100V to 240V
Maximum voltage: 90V to 264V
Frequency : 50/60 Hz
Rated current per input: 2A
HVDC input
Rated voltage: 120V to 340V
