QSW-6200 Series Switch Hardware Installation and Reference Guide 54

www.qtech.ru

Addition D Mini USB Console Driver Installation

The Mini USB Console driver can be downloaded on the official TI website (http://www.ti.com/). The driver is now

supported only on 32-bit Windows XP, 64-bit Windows XP, 32-bit Window Vista, 64-bit Window Vista, 32-bit Windows 7,

and 64-bit Windows 7.

Installation Steps

Step 1: Double click the Setup file and choose Next.

Step 2: Accept the License Agreement and click Next.
