Kohler KS540 [9/92] Speciﬁ cations

Kohler KS590 [9/92] Speciﬁ cations

9

Speciﬁ cations

22 690 01 Rev. -- KohlerEngines.com

Engine Dimensions-Valve Cover Side

F

E

G

H

I

K

A

B

D

C

J

L

M

N

O

P

A 64.2 mm (2.53 in.) B 16.0 mm (0.63 in.) C

24.3 mm (0.96 in.)

to Spark Plug

D

Cored for M6 Self

Tapping Screw

16.5 mm (0.65

in.) Min. Depth

(Accessory

Mounting

Location)

E 93.2 mm (3.67 in.) F Carburetor G Oil Drain Plug H 122.7 mm (4.83 in.)

I

6.32-6.36 mm

(0.249-0.250 in.)

Keyway Width

J

Ø 25.37-25.40 mm

(0.999-1.0 in.)

K 100.0 mm (3.94 in.) L

85.5 mm (3.37 in.)

Ground Lug

Mounting Boss

M

2 X Accessory

Mounting

Surface

N

112.6 mm (4.43 in.) to

Spark Plug

O 88.0 mm (3.47 in.) P

Cored for M6 Self

Tapping Screw

Thru (Accessory

Mounting

Location)
