Engine Dimensions with Low-Proﬁ le Air Cleaner - PTO Side

A 427.8 mm (18.84 in.) B 107.9 mm (4.25 in.) C

85.5 mm (3.37 in.)

Lifting Point

10 X 12 mm

(0.39 X 0.47 in.) Slot

E Oil Level Dipstick F M8 X 1.25 mm Studs G 45° H 35°

I 30° J

60.0 mm (2.37 in.)

Exhaust Port #1

481.2 mm (16.47 in.)

Lifting Point

L 340.8 mm (13.42 in.)

181.9 mm (7.16 in.)

Starter Stud

N Mounting Hole "A" O

68.6 mm (2.70 in.)

Starter Stud

P 106.0 mm (4.17 in.)

177.8 mm (7.01 in.)

Pilot

M8 X 1.25 mm-6H in.

25 mm (0.98 in.)

Deep on a Ø 254 mm

(10.0 in.) B.C.

4 X 7/16-14 UNC-2B in.

21 mm (0.83 in.) Deep

on a Ø 142.88 mm

(5.625 in.) B.C.

4 X 3/8-16 UNC-2B in.

17 mm (0.67 in.)

Deep on a Ø 196.88

mm (7.750 in.) B.C.

U 142.9 mm (5.63 in.) V 254.0 mm (10 in.) W 196.9 mm (7.75 in.) X

2 X 35.0 mm (1.38 in.)

Gasket

60.0 mm (2.36 in. )

Exhaust Port #2

H H
