Technical Data
Wiring and installation Dimensions (in mm) Maintenance
Application example
MLPVM2-230L-5A
INSTALLATION INSTRUCTIONS -
NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
Protection de surtentions permanentes, temporaires et
parafoudre pour éclairage à LED.
Permanent and temporary overvoltage protection and
AC surge protector for LED lighting system.
Protección AC contra sobretensiones transitorias
para iluminación con tecnología LED.
Protezione AC contra sovratensioni
per l’illuminazione con tecnologia LED.
УЗИП переменного тока
для светодиодных систем освещения.
Střídavá přepěťová ochrana pro LED osvětlovací systémy.
and replace
with
MLPVM2-230L-5A
LED OFF + AC o = Defect
LED ON = OK
N170303a
P/N
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
indoor use only
MLPVM2-230L-5A
LED on
LED o
X
I
10 kA
5 A
Class II
None
max
I
L
I
PE
Protection class
IP20
Connection by spring
230 Vac single phase
AC system :
TT/TN
Characteristics
AC network
25
59
40
30
49
Diam. 4,3
* FE : Functional Earth
Isolated Mast
Class II lighting
LED circuit board
LED
Driver
FE*
OK V+
230 Vac
Network
Surge protector
stage
Permanent and temporary
overvoltage protection stage
Safety
disconnector
Green
Voltage AC ok
AC Voltage high ≥270 V
1
2
3
Red
No AC voltage
or defect
No LED
Isolation Class
< 50 cm
Protected
Equipement
AC network
Insert
Wire
2
L
N
L
N
1.5 - 2.5 mm² 16 - 14 AWG
9 - 10 mm 0.35 - 0.39 in
min-max
min-max
Protected side
Push
1
Protected
Equipement
Automatic
reconnection
disconnect
X
