CITEL MJ6-1T Инструкция по установке онлайн

CITEL MJ6-1T Инструкция по установке онлайн
LINE
EQUIP
t
PE
Surge
Protection
Device
MaintenanceWiring
Network
MJ6-1T
Technical Data
Application example
INSTALLATION INSTRUCTIONS -
NOTICE D'INSTALLATION
NOTICIA DE INSTALACIÓN - INSTALLATIONSHINWEISE
ISTRUZIONI PER L'INSTALLAZIONE
INSTRUCOES DE INSTALACAO - MONTÁŽNÍ NÁVOD
РУКОВОДСТВО ПО МОНТАЖУ - 安装指导书
Telecom
external
network
Surge protector for telecom line
Parafoudre pour ligne télécom
N131004b
Proteccion para lineas telecom
Überspannungsschutz für telekom
Protezione per la linea telecom
Proteção para linha telecom
MJ6-1T
Line
connect RJ11 cable with MJ6-1T
Protected
equipt
AC Network
MJ6-1T
Application
Max. frequency
I/O connections
P/N
PSTN or ADSL line
170 Vdc
300 mA
> 10 MHz
RJ11 female
Max. operating voltage (UC)
Max. load current (I
L)
Din or plate
Installation
3- Bracket1- DIN-rail 2- Wire
1
2
Clip on
symmetrical
DIN rail
DIN rail adapter
screw
screw nut
DIN-rail
MJ6
1
2
mount MJ6 on
earthing plate
earthing
bracket
countersunk
screw
0.2 Nm
1.8 Lb-In
1
2
3
press cable
shoe
cable shoe
screw
screw nut
27
25
58
4
Dimensions
6500 ft max.
2000 m ma
x.
-40/+185°F max.
-40/+85°C max.
IP20
indoor use only
Humidity range
5% to 95%
Network
Characteristics
and replace
with MJ6-1T
MJ6
MJ6
X
X
X
