KSB MegaCPK 050-032-160.1 [20/30] Centrifugal pumps with shaft seal
![KSB MegaCPK 080-050-200 [20/30] Centrifugal pumps with shaft seal](/views2/1603783/page20/bg14.png)
Size
Bearing bracket
Pump dimensions
[mm]
DN1 DN2 a b c f g1 g2 h1 h2 m1 m3 n1 n3 n5
050-032-125 CS40 50 32 80 50 465 385 15 4 112 140 100 48 190 90 160
050-032-125.1 CS40 50 32 80 50 465 385 15 4 112 140 100 48 190 90 160
050-032-160 CS40 50 32 80 50 465 385 15 4 132 160 100 48 240 140 160
050-032-160.1 CS40 50 32 80 50 465 385 15 4 132 160 100 48 240 140 160
050-032-200 CS40 50 32 80 50 465 385 18 4 160 180 100 48 240 140 160
050-032-200.1 CS40 50 32 80 50 465 385 18 4 160 180 100 48 240 140 160
050-032-250 CS50 50 32 100 65 600 500 18 4 180 225 125 48 320 190 160
050-032-250.1 CS50 50 32 100 65 600 500 18 4 180 225 125 48 320 190 160
065-040-125 CS40 65 40 80 50 465 385 15 4 112 140 100 48 210 110 160
065-040-160 CS40 65 40 80 50 465 385 15 4 132 160 100 48 240 140 160
065-040-160.1 CS40 65 40 80 50 465 385 15 4 132 160 100 48 240 140 160
065-040-200 CS40 65 40 100 50 485 385 18 4 160 180 100 48 265 165 160
065-040-200.1 CS40 65 40 100 50 485 385 15 4 160 180 100 48 265 165 160
065-040-250 CS50 65 40 100 65 600 500 18 4 180 225 125 48 320 190 160
065-040-250.1 CS50 65 40 100 65 600 500 18 4 180 225 125 48 320 190 160
065-040-315 CS50 65 40 125 65 625 500 18 6 200 250 125 48 345 215 160
065-040-315.1 CS50 65 40 125 65 625 500 18 4 200 250 125 48 345 215 160
080-050-125 CS40 80 50 100 50 465 385 18 4 132 160 100 48 240 140 160
080-050-160 CS40 80 50 100 50 485 385 18 4 160 180 100 48 265 165 160
080-050-160.1 CS40 80 50 100 50 485 385 15 4 160 180 100 48 262 162 160
080-050-200 CS40 80 50 100 50 485 385 18 4 160 200 100 48 265 165 160
080-050-200.1 CS40 80 50 100 50 485 385 15 4 160 200 100 48 265 165 160
080-050-250 CS50 80 50 125 65 625 500 18 4 180 225 125 48 320 190 160
080-050-250.1 CS50 80 50 125 65 625 500 18 4 180 225 125 48 320 190 160
080-050-315 CS50 80 50 125 65 625 500 18 6 225 280 125 48 345 215 160
080-050-315.1 CS50 80 50 125 65 625 500 18 6 225 280 125 48 345 215 160
100-065-125 CS40 100 65 100 65 485 385 18 4 160 180 125 48 280 150 160
100-065-160 CS50 100 65 100 65 600 500 18 4 160 200 125 48 280 150 160
100-065-200 CS50 100 65 100 65 600 500 18 4 180 225 125 48 320 190 160
100-065-250 CS50 100 65 125 80 625 500 20 6 200 250 160 48 360 200 160
100-065-315 CS60 100 65 125 80 655 530 20 6 225 280 160 48 400 240 160
125-080-160 CS50 125 80 125 65 625 500 18 4 180 225 125 48 320 190 160
125-080-200 CS50 125 80 125 65 625 500 18 4 180 250 125 48 345 215 160
125-080-200.1 CS50 125 80 125 65 625 500 18 4 180 250 125 48 345 215 160
125-080-250 CS50 125 80 125 80 625 500 18 6 225 280 160 48 400 240 160
125-100-160 CS50 125 100 125 80 625 500 18 6 200 280 160 48 360 200 160
125-100-200 CS50 125 100 125 80 625 500 18 6 200 280 160 48 360 200 160
125-080-315 CS60 125 80 125 80 655 530 20 6 250 315 160 48 400 240 160
125-080-400 CS60 125 80 125 80 655 530 20 6 280 355 160 48 435 275 160
125-100-250 CS60 125 100 140 80 670 530 18 6 225 280 160 48 400 240 160
125-100-315 CS60 125 100 140 80 670 530 18 6 250 315 160 48 400 240 160
125-100-400 CS60 125 100 140 100 670 530 20 6 280 355 200 48 500 300 160
150-125-200 CS60 150 125 140 80 670 530 20 6 250 315 160 48 400 240 160
150-125-250 CS60 150 125 140 80 670 530 20 6 250 355 160 48 400 240 160
150-125-315 CS60 150 125 140 100 670 530 20 6 280 355 200 48 500 300 160
150-125-400 CS60 150 125 140 100 670 530 20 6 315 400 200 48 500 300 160
200-150-200 CS60 200 150 180 100 710 530 20 6 280 400 200 48 550 350 160
200-150-250 CS60 200 150 160 100 690 530 20 6 280 375 200 48 500 300 160
200-150-315 CS80 200 150 160 100 830 670 20 8 315 400 200 60 550 350 200
200-150-400 CS80 200 150 160 100 830 670 20 8 315 450 200 60 550 350 200
200-150-500 CS80 200 150 180 100 850 670 22 8 375 500 200 60 550 350 200
200-200-250 CS80 200 200 180 100 850 670 22 8 355 425 200 60 550 350 200
250-200-315 CS80 250 200 200 100 870 670 22 8 355 450 200 60 550 350 200
250-200-400 CS80 250 200 180 100 850 670 22 8 355 500 200 60 550 350 200
250-200-500 CS80 250 200 200 100 870 670 22 8 425 560 200 60 660 460 200
300-250-315 CS80 300 250 250 130 920 670 26 8 400 560 260 60 690 430 200
Centrifugal Pumps with Shaft Seal
Standardised Chemical Pumps
20
MegaCPK
