Flange design
Flange material variants
Material Europe / Northern Asia / Americas / Southern Asia Americas
G EN 1092-2 PN 16
Drilled to ASME B16.1 Class 125
ASME B16.1 Class 125
ASME B16.1 Class 250
22)
C EN 1092-1 PN 16
Drilled to ASME B16.5 Class 150
ASME B16.5 Class 150
V EN 1092-1 PN 16
Drilled to ASME B16.5 Class 150
-
D EN 1092-1 PN 25
Drilled to ASME B16.5 Class 150
Drilled to ASME B16.5, Class 300
23)
-
E EN 1092-1 PN 25
Drilled to ASME B16.5 Class 150
Drilled to ASME B16.5, Class 300
23)
ASME B16.5 Class 150
ASME B16.5Class 300
22)
Scope of supply
Depending on the model, the following items are included in
the scope of supply:
▪ Pump
Drive
▪ Surface-cooled IEC frame three-phase squirrel-cage motor
Coupling
▪ Flexible coupling with or without spacer
Contact guard
▪ Coupling guard
Baseplate
▪ Baseplate (to ISO 3661), cast or welded, for pump and
motor, in torsion-resistant design
▪ Channel section steel or folded steel plate
Special accessories
▪ As required
22)
Depending on the size
23)
Not possible for size 100-065-125
Centrifugal Pumps with Shaft Seal
Standardised Chemical Pumps
22
