Detailed designation
Designation example
Position
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
M C P K 0 5 0 - 0 3 2 - 1 2 5 1 C D H I X N C E D 1 3 2 0 6 A P D 2 E M
See name plate and data sheet See data sheet
Designation key
Position Code Description
1-4 Pump type
MegaCPK
5-16 Size
200 Nominal suction nozzle diameter [mm]
150 Nominal discharge nozzle diameter [mm]
4001 Nominal impeller diameter [mm]
17 Pump casing material
G Cast iron JL 1040/A48CL35B
C Stainless steel 1.4408/A743CF8M
E Unalloyed steel GP240GH+N/A216 GR WCB
V Stainless steel 1.4408
S Nodular cast iron JS1030/ A536 60-40-18
D Duplex Noridur 1.4593/1.4517/A995 GR1B
18 Impeller material
G Cast iron JL 1040/A48CL35B
C Stainless steel 1.4408/A743CF8M
E Unalloyed steel GP240GH+N/A216 GR WCB
D Duplex Noridur 1.4593/1.4517/A995 GR1B
S Nodular cast iron JS 1030/ A536 60-40-18
X Chrome steel A 743 GR CA6NM
19 Heatable model
-
33)
Standard
H Heatable casing
D Orifice plate
Z Orifice plate and heatable casing
20 Hydraulic system
-
33)
Standard
I With auxiliary impeller
21 Special design
-
33)
Standard
X Special design
22 Bearing bracket
N Normal (economy bearings)
M Normal (medium-duty bearings)
C Normal, coolable (medium-duty bearings)
F Fire-fighting system
23-25 Seal options
P1 Gland packing variant with internal barrier fluid (Na)
P2 Gland packing variant without barrier fluid (Nb)
P3 Gland packing variant with external barrier fluid (Nc)
E External circulation
EQ External circulation with lip seal as quench seal
ED External circulation with throttling bush as quench seal
I Internal circulation
IQ Internal circulation with lip seal as quench seal
ID Internal circulation with throttling bush as quench seal
IH Internal circulation with heatable casing cover
IQH Internal circulation with heatable casing cover and lip seal as
quench seal
IDH Internal circulation with heatable casing cover and throttling bush
as quench seal
33)
Blank
Centrifugal Pumps with Shaft Seal
Standardised Chemical Pumps
MegaCPK
27
