Attaching the OTA to a mount

Your OTA comes with a pair of hinged tube rings that may be used to attach the optical tube to a mount or a guidescope to the

OTA.

Once you have attached your optical tube to a mount, you might have to balance the assembly. Loosen the ring clamps and slide

the optical tube forward or backward within the tube rings to balance it. Do not forget to retighten the ring clamps afterward.

Finderscope assembly

A nderscope is a small wide-eld telescope used to help locate and center objects in the eld of view of the optical tube. To

install the nderscope follow these simple steps:

1. Locate the nderscope bracket and remove the rubber ring from it;

2. Slide the rubber ring into the groove at the center of the nderscope tube;

3. Slide the nderscope bracket into the mount on the optical tube and tighten the screw to hold the bracket in place;

4. Loosen two adjustment thumbscrews on the bracket and pull the spring pin;

5. Slide the nderscope tube into the bracket until the rubber ring sits in the bracket;

6. Release the spring pin and retighten the thumbscrews.

Aligning the nderscope

The nderscope and the main telescope have to be aligned so that they point to the same spot in the sky. Alignment is best done

outdoors during the day, when it is easier to locate objects. Note that you will have to use the 35-mm extension adapter to reach

focus with most eyepieces. First, insert an eyepiece (an eyepiece with a reticle is recommended) into the 35-mm extension

adapter and insert the adapter into the focuser. Point the telescope at an object at least 500 yards away. Adjust the telescope

so that the target object appears in the center of the eld of view in the eyepiece. Check the nderscope to see if the object is

also centered there. If it is not centered, use the adjustment thumbscrews to center the object in the eld of view.

It is recommended to check the alignment before every stargazing or astrophotography session. Alignment can be done at night,

as well. Choose any bright star or a planet, center the object in the telescope eyepiece, and then use the adjustment thumb-

screws until the star or the planet is also centered in the nderscope.

Focusing the nderscope

If the image in the nderscope appears out of focus, you will have to refocus it. First, loosen the locking ring located behind

the objective lens cell on the nderscope body. Then, focus your view by rotating the objective lens cell in either direction.

Once the image appears sharp, retighten the locking ring behind the objective lens cell.

Eyepiece assembly

An eyepiece magnies the image produced by the OTA. The eyepiece is installed into the focuser. Eyepieces are commonly re-

ferred to by their focal length and barrel diameter. The focal length of each eyepiece is printed on the eyepiece shell. The longer

the focal length, the lower the eyepiece magnication, and vice versa. The total power of the telescope setup may be calculated

with the following formula:

Magnication = Focal Length of Telescope (mm) / Focal Length of Eyepiece (mm)

To install an optional eyepiece:

1. Loosen the screw on the focuser;

2. Slide the eyepiece into the focuser;

3. Retighten the screw to secure the eyepiece in place.

Telescope assembly

Levenhuk Ra Reectors OTA

Congratulations on your purchase of a high-quality Levenhuk telescope!

These instructions will help you set up, properly use, and care for your telescope. Please read them thoroughly before getting

started.

All parts of the telescope will arrive in one box. Be careful when unpacking it. We recommend keeping the original shipping con-

tainers. In the event that the telescope needs to be shipped to another location, having the proper shipping containers will help

ensure that your telescope survives the journey intact. Make sure all the parts are present in the packaging. Be sure to check the

box carefully, as some parts are small. No tools are needed other than those provided. All screws should be tightened securely to

eliminate exing and wobbling, but be careful not to overtighten them, as that may strip the threads.

During assembly (and anytime, for that matter), do not touch the surfaces of the optical elements with your ngers. The optical

surfaces have delicate coatings on them that can easily be damaged if touched. Never remove mirrors from their housing, or the

product warranty will be null and void.

CAUTION! Never look directly at the Sun – even for an instant – through your telescope or nderscope without a professionally

made solar lter that completely covers the front of the instrument, or permanent eye damage may result. To avoid damage

to the internal parts of your telescope, make sure the front end of the nderscope is covered with aluminum foil or another

non-transparent material. Children should use the telescope under adult supervision only.
