10
INTRODUCTINTRODUCT
INTRODUCTINTRODUCT
INTRODUCT
IONION
IONION
ION
33, 46, 66, 92SV SERIES33, 46, 66, 92SV SERIES
33, 46, 66, 92SV SERIES33, 46, 66, 92SV SERIES
33, 46, 66, 92SV SERIES
ELECTRIC PUMP CROSELECTRIC PUMP CROS
ELECTRIC PUMP CROSELECTRIC PUMP CROS
ELECTRIC PUMP CROS
S SECTION AND MAIN COMPONENTSS SECTION AND MAIN COMPONENTS
S SECTION AND MAIN COMPONENTSS SECTION AND MAIN COMPONENTS
S SECTION AND MAIN COMPONENTS
G VERSIONSG VERSIONS
G VERSIONSG VERSIONS
G VERSIONS
MATERIALI 33-92SV VERSIONI G
REF. NAME MATERIAL
N. EUROPE USA
1 Pum
p
bod
y
Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
1A Lower su
pp
ort Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
2 Im
p
elle
r
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
3 Diffuser Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
4 Outer sleev
e
Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
5 Shaft Stainless steel EN 10088-1 - X17CrNi16-2 (1.4057) AISI 431
6 Ada
p
ter Cast iron EN 1561-GJL-200 (JL1030) ASTM Class 25
7 Wear rin
g
8 Cou
p
lin
g
Cast iron EN 1561-GJL-200 (JL1030) ASTM Class 25
9 U
pp
er head Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
9A Seal housin
g
Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
10 Mechanical seal
11 Elastomers
12 Cou
p
lin
g
p
rotection Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
13 Shaft sleeve and bushin
g
14 Bushin
g
for diffuse
r
15 Fill / Drain
p
lu
g
s Stainless steel EN 10088-1-X5CrNiMo17-12-2 (1.4401) AISI 316
16 Tie rods Galvanized steel EN 10277-3-36SMnPb14 (1.0765) -
33-92sv-g-en_a_tm
Carbon
Technopolymer PPS
REFERENCE STANDARDS
Silicon carbide / Carbon / EPDM
EPDM
Tungsten carbide
MATERIALI 33-92SV VERSIONI N
REF. NAME MATERIAL
N. EUROPE USA
1 Pum
p
bod
y
Stainless steel EN 10213-4-GX5CrNiMo19-11-2 (1.4408) ASTM CF8M (AISI 316 cast)
1A Lower su
pp
ort Stainless steel EN 10213-4-GX5CrNiMo19-11-2 (1.4408) ASTM CF8M (AISI 316 cast)
2 Im
p
elle
r
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
3 Diffuser Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
4 Outer sleev
e
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
5 Shaft Du
p
lex stainless steel EN 10088-1-X2CrNiMoN22-5-3 (1.4462) UNS S 31803
6 Ada
p
ter Cast iron EN 1561-GJL-200 (JL1030) ASTM Class 25
7 Wear rin
g
8 Cou
p
lin
g
Cast iron EN 1561-GJL-200 (JL1030) ASTM Class 25
9 U
pp
er head Stainless steel EN 10213-4-GX5CrNiMo19-11-2 (1.4408) ASTM CF8M (AISI 316 cast)
9A Seal housin
g
Stainless steel EN 10213-4-GX5CrNiMo19-11-2 (1.4408) ASTM CF8M (AISI 316 cast)
10 Mechanical seal
11 Elastomers
12 Cou
p
lin
g
p
rotection Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
13 Shaft sleeve and bushin
g
14 Bushin
g
for diffuse
r
15 Fill / drain / air
p
lu
g
s Stainless steel EN 10088-1-X5CrNiMo17-12-2 (1.4401) AISI 316
16 Tie rods Stainless steel EN 10088-1-X17CrNi16-2 (1.4057) AISI 431
33-92sv-n-en_a_tm
Carbon
Technopolymer PPS
REFERENCE STANDARDS
Silicon carbide / Carbon / EPDM
EPDM
Tungsten carbide
N VERSIONSN VERSIONS
N VERSIONSN VERSIONS
N VERSIONS
