8
INTRODUCTINTRODUCT
INTRODUCTINTRODUCT
INTRODUCT
IONION
IONION
ION
1, 3, 5SV SERIES and 10, 15, 22SV SERIES 1, 3, 5SV SERIES and 10, 15, 22SV SERIES
1, 3, 5SV SERIES and 10, 15, 22SV SERIES 1, 3, 5SV SERIES and 10, 15, 22SV SERIES
1, 3, 5SV SERIES and 10, 15, 22SV SERIES
≤≤
≤≤
≤
4 kW 4 kW
4 kW 4 kW
4 kW
ELECTRIC PUMP CROSELECTRIC PUMP CROS
ELECTRIC PUMP CROSELECTRIC PUMP CROS
ELECTRIC PUMP CROS
S SECTION AND MAIN COMPONENTSS SECTION AND MAIN COMPONENTS
S SECTION AND MAIN COMPONENTSS SECTION AND MAIN COMPONENTS
S SECTION AND MAIN COMPONENTS
MATERIALI 1-22 SV VERSIONI F-T-R
REF. NAME MATERIAL
N. EUROPE USA
1 Pum
p
bod
y
Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
2 Im
p
elle
r
Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
3 Diffuser Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
4 Outer sleev
e
Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
5 Shaft Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
6 Ada
p
ter Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
7 Base Aluminium EN 1706-AC-AlSi11Cu2 (Fe) (AC46100) -
8 Cou
p
lin
g
Aluminium EN 1706-AC-AlSi11Cu2 (Fe) (AC46100) -
9 Seal housin
g
Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
10 Mechanical seal Silicon carbide / Carbon / EPDM
11 Elastomers EPDM
12 Cou
p
lin
g
p
rotection Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
13 Shaft sleeve and bushin
g
Tun
g
sten carbide
14 Fill / drain
p
lu
g
s Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
15 Tie rods Galvanized steel EN 10277-3-36SMnPb14 (1.0765)
16 Wear rin
g
Techno
p
ol
y
mer PPS
1-22sv-ftr-en_a_tm
REFERENCE STANDARDS
MATERIALI 1-22SV VERSIONI N-V-C-K
REF. NAME MATERIAL
N. EUROPE USA
1 Pum
p
bod
y
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
2 Im
p
elle
r
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
3 Diffuser and u
pp
er s
p
ace
r
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
4 Outer sleev
e
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
5 Shaft Stainless steel EN 10088-1-X5CrNiMo17-12-2 (1.4401) AISI 316
6 Ada
p
ter Cast iron EN 1561-GJL-250 (JL1040) ASTM Class 35
7 Base Aluminium EN 1706-AC-AlSi11Cu2 (Fe) (AC46100) -
8 Cou
p
lin
g
Aluminium EN 1706-AC-AlSi11Cu2 (Fe) (AC46100) -
9 Seal housin
g
Stainless steel EN 10088-1-X2CrNiMo17-12-2 (1.4404) AISI 316L
10 Mechanical seal Silicon carbide / Carbon / EPDM
11 Elastomers EPDM
12 Cou
p
lin
g
p
rotection Stainless steel EN 10088-1-X5CrNi18-10 (1.4301) AISI 304
13 Shaft sleeve and bushin
g
Tun
g
sten carbide
14 Fill / drain
p
lu
g
s Stainless steel EN 10088-1-X5CrNiMo17-12-2 (1.4401) AISI 316
15 Tie rods Stainless steel EN 10088-1-X17CrNi16-2 (1.4057) AISI 431
16 Wear rin
g
Techno
p
ol
y
mer PPS
1-22sv-nvck-en_a_tm
REFERENCE STANDARDS
N, VN, V
N, VN, V
N, V
, C, K VERSIONS, C, K VERSIONS
, C, K VERSIONS, C, K VERSIONS
, C, K VERSIONS
FF
FF
F
, T, T
, T, T
, T
, R VERSIONS, R VERSIONS
, R VERSIONS, R VERSIONS
, R VERSIONS
