6
INTRODUCTINTRODUCT
INTRODUCTINTRODUCT
INTRODUCT
IONION
IONION
ION
Special versions and options indexSpecial versions and options index
Special versions and options indexSpecial versions and options index
Special versions and options index
The first part of this booklet will cover the following special
versions:
- e-SV
TM
– High Pressure - 50/60 Hz
- e-SV
TM
– Low NPSH - 50/60 Hz
- e-SV
TM
– High Temperature - 150°C & 180°C
- e-SV
TM
– with Hydrovar
®
- SVH
- e-SV
TM
– 4-pole version - 50/60 Hz
- e-SV
TM
– Reducing footprint - 50/60 Hz
- e-SV
TM
– Horizontal version - 50/60 Hz
The second part of this booklet will cover the following
sections:
- Motors configuration and standard options
- Dry-running sensor
- i-Alert device
- Tests and certifications
- Accessories
Documentation and supportDocumentation and support
Documentation and supportDocumentation and support
Documentation and support
Pump selection software, visit:
http://www.xylect.com
Documentation is also available on:
http://www.lowara.com
Visit us for information including video, commercial
leaflet, brochure, other technical catalogues, 2D and 3D
drawings, IOM.
IntroductionIntroduction
IntroductionIntroduction
Introduction
Our customers are central to our business.
Many years of collaboration with them across the different
markets and all over the world has taught us that
specifically designed pumps are required to handle special
applications or to fulfill particular installations. It is essential
to ensure top performance of the systems and continuous
quality of the production.
Therefore Lowara has developed a wide range of special
versions of its vertical multistage e-SV
TM
to give an
appropriate and dedicated solution to special applications
and installations in the industry or in the building services
market.
Pump designPump design
Pump designPump design
Pump design
Non-self priming, vertical multistage, high pressure
centrifugal pump, with suction inlet and outlet of the same
identical nominal diameters, coupled to a standard motor.
Horizontal installation also available, see specific section.
DriveDrive
DriveDrive
Drive
Without speed control:Without speed control:
Without speed control:Without speed control:
Without speed control: Electric short-circuit squirrel-
cage motor (TEFC), enclosed construction, air-cooled,
three-phase, 2-pole and 4-pole, efficiency class
IE2/IE3IE2/IE3
IE2/IE3IE2/IE3
IE2/IE3
from 0,75kW (compliant with Regulation (EC) no. 640/
2009 and IEC 60034-30).
Single-phase version up to 2,2 kW (with built-in automatic
reset overload protection up to 1,5kW).
With HydrovarWith Hydrovar
With HydrovarWith Hydrovar
With Hydrovar
®®
®®
®
speed control system speed control system
speed control system speed control system
speed control system:
A special
version of e-SV
TM
which becomes an intelligent, variable
speed system. Ideal for single pumping solution or multiple
pumping set solution (up to 8 pumps). See specific section
of e-SVH – Hydrovar
®
fitted.
For more motor options see the specific motors section.
e-SV™ SERIES - SPECIAL VERSIONSe-SV™ SERIES - SPECIAL VERSIONS
e-SV™ SERIES - SPECIAL VERSIONSe-SV™ SERIES - SPECIAL VERSIONS
e-SV™ SERIES - SPECIAL VERSIONS
