60
ESH SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
ESH 25-250 ~ 1450 [rpm] ISO 9906:2012 - Grade 3B
0 10 20 30 40 50 60
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
Q [Imp gpm]
Q [l/s]
25-250/15
Ø244.5
25-250/11
Ø223.5
25-250/07
Ø203
46.7
46.6
46.6
45
45
43
41
39
37
35
0 10 20 30 40 50 60 70
0
10
20
30
40
50
60
70
0
2
4
6
8
10
12
14
16
18
20
22
Q [US gpm]
H [ft]
H[m]
η[%]
25-250/15
Ø244.5
0
5
10
15
0
2
4
6
NPSH [ft]
NPSH[m]
25-250/15
Ø244.5
25-250/11
Ø223.5
25-250/07
Ø203
0.0
0.5
1.0
1.5
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
0 2 4 6 8 10 12 14 16 18
P
P
[HP]
Pp[kW]
Q [m
3
/h]
ESH25
-
250_4P50_C_CH
