67
ESH SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
ESH 40-200 ~ 1450 [rpm] ISO 9906:2012 - Grade 3B
0 20 40 60 80 100
012345678
Q [Imp gpm]
Q [l/s]
40-200/11
Ø209
40-200/07
Ø190
62.9
64.3
63
63
62
62
60
60
58
58
55
0 20 40 60 80 100 120
0
5
10
15
20
25
30
35
40
45
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Q [US gpm]
H [ft]
H[m]
η[%]
40-200/11
Ø209
0
2
4
6
8
0
1
2
3
NPSH [ft]
NPSH[m]
40-200/11
Ø209
40-200/07
Ø190
0.0
0.2
0.4
0.6
0.8
1.0
1.2
0.0
0.2
0.4
0.6
0.8
1.0
0 5 10 15 20 25 30
P
P
[HP]
Pp[kW]
Q [m
3
/h]
ESH40
-
200_4P50_A_CH
