![Lowara ESHE 32-250/07/X45RSNA [65/120] Esh series operating characteristics at 50 hz 4 poles](/img/pdf.png)
Lowara ESHE 32-250/07/X45RSNA [65/120] Esh series operating characteristics at 50 hz 4 poles
![Lowara ESHE 32-250/07/X45RSNA [65/120] Esh series operating characteristics at 50 hz 4 poles](/views2/1614666/page65/bg41.png)
65
ESH SERIES
OPERATING CHARACTERISTICS AT 50 Hz, 4 POLES
The NPSH values are laboratory values; for practical use we suggest increasing these values by 0,5 m.
These performances are valid for liquids with density ρ = 1,0 Kg/dm
3
and kinematic viscosity ν = 1 mm
2
/sec.
ESH 40-125 ~ 1450 [rpm] ISO 9906:2012 - Grade 3B
0 10 20 30 40 50 60 70 80 90
0123456
Q [Imp gpm]
Q [l/s]
40-125/02
Ø133
40-125/02A
Ø125
68.1
69.2
67
67
65
65
63
63
61
61
59
59
68
68
0 20 40 60 80 100
0
5
10
15
0
1
2
3
4
5
6
Q [US gpm]
H [ft]
H[m]
η[%]
η[%]η[%]
η[%]
40-125/02
Ø133
0
2
4
6
0
1
2
NPSH[ft]
NPSH[m]
40-125/02
Ø133
40-125/02A
Ø125
0.0
0.1
0.2
0.3
0.4
0.0
0.1
0.2
0.3
0 5 10 15 20 25
Pp[HP]
Pp[kW]
Q [m
3
/h]
ESH40
-
125_4P50_C_CH
