SENA 10UPAD [10/48] Package contents

10Upad

2 PACKAGE CONTENTS

2.1 10Upad for HJC IS-17

•CheekPadSystemLeft 

•CheekPadSystemRight 

•USBPower&DataCable 

2.2 10Upad for HJC IS-MAX2

•CheekPadSystemLeft 

•CheekPadSystemRight 

•USBPower&DataCable 
