10Upad
12
3.2 10Upad for HJC IS-MAX2 Installation Guide
Connection Cable
Left Speaker
Microphone
Right Speaker
Connection Cable
10Upad for HJC IS-MAX2
4. Connect the connection cables and store it behind the internal
padding of the helmet.
