Worx WX066 [11/32] Drill driver en

Drill

Driver EN

OPERATING INSTRUCTIONS

NOTE: Before using the tool, read the instruction book carefully.

ASSEMBLY AND OPERATION

ACTION FIGURE

BEFORE OPERATION

Removing the Battery Pack See Fig. A1

Charging the Battery Pack See Fig. A2

Installing the Battery Pack See Fig. A3

ASSEMBLY

Bit Lock

Adjustment

WARNING: Always ensure the bit is secure before starting the tool.

Damage to the Chuck or a loose bit may cause possible personal injury.

NOTE: When the chuck jaws become fully opened or closed, the clutch will

activate, making a clicking sound. This sound is normal.

If the Bit Lock

Switch (10) does not operate, conﬁrm the battery is charged and

depress the trigger brieﬂy.

Keep drill tilted upward when adjusting the chuck to prevent bit from falling out.

--Inserting the Bits See Fig. B1

--Removing the Bits See Fig. B2

OPERATION

Forward/Reverse Rotation Switch

WARNING: Never change the direction of rotation when the Chuck is

rotating. Wait until it has stopped!

See Fig. C1,

C2, C3

Function Mode Selection

Press the function button to select operation mode. The button will illuminate

in blue for a few seconds. Depress the Variable Speed Switch (9) slightly to

illuminate the function button again .

Drive Mode with Safe Drive

• When driving a screw, the tool automatically stops as the screw head becomes

ﬂush with surface of workpiece. If a deeper screw is desired, continue to depress

the Variable Speed Switch (9). The tool will make slow rotations to drive the screw

deeper.

• Once the desired depth is reached, release the Variable Speed Switch (9).

NOTE: If the tool stops sooner than desired, release the Variable Speed Switch (9)

and press it again to reset the tool.

See Fig. D

Drill Mode See Fig. E
