Drill

Driver EN

Pulse Assist Mode

WARNING: Do not work for long periods with the Pulse Assist Mode

activated as the motor can be overheated.

NOTE: Pulse Assist Mode is very effective to prevent stripping screws, removing

stubborn screws and to prevent the bit tip from walking when drilling on smooth

surfaces. When the Pulse Assist Mode is activated, it can be switched with the

drill/drive mode.

• Make sure the Forward/Reverse Rotation Switch (4) is pushed to the left or right

and the Pulse Assist Mode is selected.

• Press the Variable Speed Switch (9), the tool will begin to rotate at a controllable

pace.

See Fig. F

Variable Speed Switch

WARNING: Do not operate for long periods at low speed because excess

heat will be produced internally.

See Fig. G

Using the LED light

To turn on the light, press the Variable Speed Switch (9) and make sure the

Forward/Reverse Rotation Switch (4) is on right or left position. When you release

the Variable Speed Switch (9), the light will go off after a moment.

The LED Light is also a battery capacity indicator. It will ﬂash when power gets

low.

The tool and battery pack are equipped with a protection system. When the LED

Light is quickly ﬂashing, the system will automatically cut power to the tool to

extend battery life. The tool will automatically stop during operation if the tool

and/or battery pack are placed under one of the following conditions:

• Overloaded: The tool is operated in a manner that causes it to draw an

abnormally high current. In this situation, release the Variable Speed Switch on

the tool and stop the application that caused the tool to become overloaded. Then

pull the Variable Speed Switch again to restart.

• Overheated: Under the condition above, if the tool does not start, the tool and

Battery Pack are overheated. Let the tool and Battery Pack cool before pulling the

Variable Speed Switch again.

• Low battery voltage: The remaining Battery capacity is too low and the tool

will not operate. Remove and recharge the Battery Pack.

See Fig. G
