Viper AS380/15C-EU (50000201) [5/150] After using the machine

1 Unscrew the drain cap (22) on the bottom of solution tank. The solution/water will flow

freely into a bucket or floor drain.

2 Rinse the solution tank with clean water after every use. This will help prevent chemical

build up and clogging of the solution lines.

3 Screw up the drain cap (22).

Recovery tank draining

NOTE

Recovery tank should be drained and cleaned after each scrubber operation is

completed.

1 Turn the latch (17) off the recovery tank, take off the recovery tank from machine by

grasping two grooves of tank. Open the lid (1) and overturn the recovery tank to

drain the dirty water into a container, or unscrew the drain cap (22) to let water pipe

out to a bucket.

2 Clean and Rinse the recovery tank with clean water after every use.

3 Re-place the recovery tank on the machine and turn the latch (17) to lock the tank..

MACHINE OPERATION

1 Set the handle to a comfortable height by pressing lever (25).

2 Lower the squeegee (33) onto the floor by pulling down the lift mechanism (26).

3 Ensure that the AC cable is connected to a corresponding voltage power supply.

4 Turn on the brush motor switch (48) and the solution switch (50), the indicator light will be on.

5 Turn on the vacuum motor switch (49), the indicator light will be on.

6 If necessary, adjust the water flow by turn the ball valve (31) manually

7 Pull one or both operating triggers (24), and then brush will start to spin, solution will begin to flow.

Move the machine and start cleaning.

CAUTION！

Before lifting the brush/pad, please disconnect AC cable from outlet (16).

CAUTION！

When cleaning excessively aggressive floors or others this could cause the machine not to

work, the three switches on the control panel may turn off. It means the machine is being

overloaded. Please press the overload protector(29),then turn on all the switches on the

Control panel (47).

AFTER USING THE MACHINE

After scrubbing, please proceed with below actions before leaving the machine:

1 Remove the brush/pad-holder.

2 Empty the tanks as shown in the previous paragraph.

3 Perform the daily maintenance procedures (see the maintenance chapter).

4 Store the machine in a clean and dry place, with the brush/pad-holder and the squeegee

5 If storing in an area which may reach freezing temperatures, be sure to drain all fluids from the

machine prior to storage. any damage caused by freezing temperatures will not be covered by the

warranty.
