Sdmo PERFORM 4500XL [12/24] Cleaning the air filter

7.5. Cleaning the air filter

Never use petrol or solvents with a low flash point for cleaning the air filter element (risk of fire or explosion).

Important

n Loosen the fasteners of the air filter cover (fig. D - No. 1) and remove the air filter cover (fig. D - No. 2).

o Remove the filtering elements (fig. D - No. 3 & 4) for cleaning.

Paper element (fig. D - No. 3):

3) Gently tap the element several times on a hard surface in order to remove excess dirt.

4) Replace the paper element if it is too dirty.

Foam element (fig. D - No. 4):

3) Wash the element in a household cleaning solution & hot water, and then rinse it thoroughly.

OR: Wash it in a non-flammable or high flash point solvent. Allow the element to dry fully.

4) Dip the element in clean engine oil and remove the excess oil.

Note: The engine will emit smoke when it is started for the first time if too much oil remains in the foam.

p Check carefully that the two elements are not torn or pierced. Replace them if they are damaged.

q Carry out refitting following the reverse procedure for removal.

7.6. Cleaning the spark arrester

n Unscrew the fixing screw of the spark arrester (fig. E - No. 2).

o Remove the spark arrester (fig. E - No. 3).

p With the help of a wire brush, remove the carbon deposits from the screen of the spark arrester.

N.B.: The spark arrester must not be pierced or cracked. Replace if necessary.

q Refit the spark arrester on the exhaust silencer protection (fig. E - No. 1).

r Screw the spark arrester fixing screw back on.

7.7. Checking the spark plug

n Remove the cap (fig. F - No. 1) from the spark plug, then remove the spark plug (fig. F - No. 2) using a spark plug spanner.

o Check the condition of the spark plug:

If the electrodes are worn or if the insulation is split or flaking: Otherwise:

p Replace the spark plug.

q Fit a new spark plug in position and tighten it by hand to

avoid damaging the threads.

r Use a spark plug spanner to tighten the spark plug by 1/2

turn after it is seated to compress the washer.

p Clean the spark plug with a metal brush.

q With a feeler gauge, check the electrode gap "X": it must be

between 0.7 and 0.8 mm inclusive.

r Check the condition of the washer.

s Fit the spark plug in position and tighten it by hand to avoid

damaging the threads.

t Use a spark plug spanner to tighten it by 1/8-1/4 turn after it

is seated to compress the washer.

7.8. Cleaning the generating set

Cleaning with a water jet is not recommended.

Cleaning with high pressure cleaning equipment is forbidden.

Important

To clean the generating set:

n Remove all dust and debris from around the exhaust.

o Clean the generating set, particularly the alternator and engine air inlets and outlets, using a cloth and brush.

p Check the general condition of the generating set and replace any faulty parts.
