Sdmo PERFORM 4500XL [9/24] Checking the fuel level

3.4. Checking the fuel level

Filling up with fuel must be carried out when the engine is stopped and in accordance with

safety instructions (see. § Filling with fuel).

Dange

Check the fuel level. Top-up if necessary:

n Unscrew the fuel tank plug (fig. A - No. 3).

o Fill up the fuel tank with the help of a funnel, without removing the fuel strainer (fig. A - No. 4) and take care not to spill any fuel.

Use only clean fuel without any presence of water.

Do not overfill the tank (there should not be any fuel in the filler neck).

After filling, always check that the fuel tank plug is properly closed.

If any fuel has been spilled, ensure that it has dried and that the vapours have evaporated before starting the

generating set.

Important

p Screw the fuel tank plug carefully back on.

3.5. Checking the air filter

Never use petrol or solvents with a low flash point for cleaning the air filter element (risk of fire or explosion).

Important

n Loosen the air filter cover fasteners (fig. D - No. 1).

o Remove the air filter cover (fig. D - No. 2) then the filtering elements (fig. D - No. 3 & 4) and visually check their condition.

p Clean or replace the elements if necessary (see. § Cleaning the air filter).

q Refit the filtering elements and the air filter cover.

r Tighten the air filter cover fasteners.

4. Using the generator set

Before use:

- make sure you know how to stop the generating set in the event of an emergency,

- make sure you completely understand all the controls and operations.

To stop the generating set urgently, place the engine switch on "OFF" or "О".

Warning

4.1. Starting procedure

n Check that the generating set is properly connected to the ground (see § Earthing the generating set).

o Select the air filter position (fig. A - No. 12) according to the conditions of usage:

- For normal temperatures, select the “Normal” position (fig. D - No. 5),

- For low temperatures, select the “Low temperatures” position (fig. D - No. 6).

p Open the fuel tap (fig. A - No. 5 & fig. C - No. 1) to “

”

”.

q Set the choke knob (fig. A - No. 6) to position “ ”.

N.B: Do not use the choke when the engine is hot or when the atmospheric temperature is high.

r Set the start & stop control (fig. A - No. 7) to “

”

or to

“

”

”.

s Slowly pull the recoil starter handle once (fig. A - No. 8) until encountering resistance, allow it to return gently.

t Then, give the recoil starter handle a quick firm pull till the engine starts.

u Gently set the choke knob to “ ” position and wait for the engine temperature to rise before using the generating set.

If the engine does not start, repeat the operation till the engine starts-up by gradually opening the choke.

4.2. Operation

When the running speed of the generating set has stabilised (approximately 3 minutes):

n Check that the circuit breaker (fig. A - No. 9) is pushed in. Press on it if necessary.

o Connect the devices to be used on the electrical sockets (fig. A - No. 10) of the generating set.

N.B: These generating sets are equipped with “Schucco” type sockets: in exceptional cases it may happen that some devices

cannot be connected. In this case, an adapter will be provided free of charge upon request to the sales office (upon presentation of

proof of purchase).
