ENGLISHen
10
- Turn the chuck lock (3) in the direction of the arrow
until the stop (a) and remove chuck (b).
Replacing the chuck:
See page 2, fig. D.
- Put the chuck onto the spindle (6) (a).
- Turn the chuck lock (3) in the direction of the arrow
(b) until the chuck can be pushed completely onto
the spindle and release the chuck lock.
- Check to see that the chuck is properly seated.
Note: To prevent the spindle from rotating when the
chuck is being changed, put the switch button (10)
to chiselling .
7.7 Tool change with SDS chuck
Before fitting, clean tool shank and apply
special grease (accessories order no.
6.31800)! Use only SDS-Plus tools.
Inserting tools:
- Turn tool and insert until it engages. The tool is
automatically locked.
Remove the tool:
See page 2, fig. A.
- Pull tool lock (2) backwards in direction indicated
by arrow (a) and remove tool (b).
7.8 Tool change keyless chuck (depends on
equipment)
Use the keyless chuck when drilling without impact
into metal, wood etc. and for driving in screws.
Clamp tool (see p.2, fig. B):
Turn sleeve (5) in direction “OPEN, RELEASE” (a).
Insert tool as deeply as possible (b) and turn sleeve
in the opposite direction, until any perceptible
mechanical resistance is overcome (c). Caution!
The tool is not yet clamped!
Continue to turn vigorously(you must hear a
“click”), until you cannot turn any further - only
now is the toolsafely clamped.
Notes: The rattling that might be heard after
opening the chuck (depending on the function) can
be eliminated by turning the sleeve into the other
direction.
With a soft tool shank, retightening may be required
after a short drilling period.
Always keep thespindle (6)clean and grease it a
bit. (Special grease: Order No.: 6.31800)
Clean (4) keyless chuck:
After prolonged use, hold the chuck vertically with
the opening facing downwards and fully open and
close it several times. The dust collected falls from
the opening. Regular use of cleaning spray on the
jaws and jaw openings is recommended.
Vent slots:
The vent slots of the machine should be cleaned
periodically.
If the trigger button (15) cannot be pressed, check,
if the rotation selector switch (13) is completely in
position R or L.
Electronic signal display (11):
- Fast flashing - restart protection
When power is restored after a power failure, the
machine - which is still switched on - will not start
for safety reasons. To continue operation, switch
the tool off and then on again.
f
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Fit accessories securely. If the machine is operated
in a holder: secure the machine well. Loss of control
can cause personal injury.
For a complete range of accessories, see
www.metabo.com or the catalogue.
Repairs to electrical tools must ONLY be carried out
by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
tools, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! Used
power tools must be collected separately and
handed in for environmentally compatible recycling
in accordance with European Directive 2002/96/EC
on waste electrical and electronic equipment and its
implementation in national legal systems.
f
Explanatory notes on the specifications on page 3.
Subject to change in accordance with technical
progress.
P
1
=Rated input
P
2
= Power output
n
1
= no-load speed
n
2
= on-load speed
ø
max
= Maximum drill diameter
s
max
=Maximum impact rate
W = Single impact force
S = Impact performance
b=Chuck clamping range
m = Weight without mains cable
8. Maintenance and Cleaning
9. Troubleshooting
10. Accessories
11. Repairs
12. Environmental Protection
13. Technical Data
