Превью страниц Страница 9 / 88
Husqvarna 325R (9679084-02) [9/88] Introduction
Contents
Introduction...................................................................9
Safety........................................................................... 10
Assembly.....................................................................14
Operation.....................................................................15
Maintenance................................................................ 17
Troubleshooting......................................................... 19
Transportation, storage and disposal...................... 19
Technical data.............................................................20
Accessories.................................................................21
EC Declaration of Conformity....................................22
Introduction
Operator's manual
The initial language of this operator's manual is English.
Operator's manuals in other languages are translations
from English.
Intended use
Use the product with a grass blade or a trimmer head to
cut different types of vegetation.
Note: National regulations can set limit to the operation
of the product.
Product overview
(Fig. 1)
1. Trimmer head
2. Grease filler cap
3. Bevel gear
4. Cutting attachment guard
5. Shaft
6. Stop switch
7. Throttle trigger
8. Throttle trigger lockout
9. Handlebar
10. Harness clamp
11. Starter housing
12. Spark plug cap, spark plug
13. Starter rope handle
14. Fuel tank
15. Air filter cover
16. Air purge bulb
17. Choke control
18. Handle adjustment
19. Throttle wire
20. Fast idle button
21. Harness
22. Combination wrench
23. Operator's manual
24. Transport guard
25. Blade
26. Support cup
27. Support flange
28. Locknut
29. Drive disc
30. Locking pin
31. Hex key
Symbols on the product
(Fig. 2) WARNING! This product is dangerous.
Injury or death can occur to the operator or
bystanders if the product is not used
carefully and correctly. To prevent injury to
the operator or bystanders, read and obey
all safety instructions in the operator's
manual.
(Fig. 3) Please read the operator's manual carefully
and make sure that you understand the
instructions before use.
(Fig. 4) Use a protective helmet in locations where
objects can fall on you. Use approved
hearing protection. Use approved eye
protection.
(Fig. 5) Use approved protective gloves.
(Fig. 6) Use heavy-duty slip-resistant boots.
(Fig. 7) The arrows show the limits for the position of
the handle.
(Fig. 8) The product can cause objects to eject,
which can cause injury.
(Fig. 9) Maximum speed of the output shaft.
881 - 001 - 10.10.2018 9
