10
EN
CAUTION!
When the polisher is switched off, thepolishing tool continues running briefly.
NOTE
Following a tool change (e.g. wool pad instead of polishing sponge), the diffe-
rence in weight may increas e the vibrations. Change the operating speed with
the adjusting wheel (button) until the vibrations have been reduced.
• Switch on the machine before placing it on the surface which is to be
polished and run the polisher up to the set speed.
• Applying light contact pressure, move the polisher in circular, overlapping
movements on the surface which is to bepolished in order to obtain a good
polishing finish and to ensure that the tool has a long service life.
• On sensitive surfaces (e.g. car paintwork) do not work aggressively butwork
at slow speeds applying low contact pressure.
• If using a polishing paste, use the respective tool for each paste.
WARNING!
Before carrying out any work on the polisher, always pull out the mains plug.
Cleaning
• Regularly clean the power tool and ventilation slots. Frequency of cleaning
is dependent on the material and duration of use.
• Regularly blow out the housing interior and motor with dry compressed air.
Carbon brushes
NOTE
Use only original par ts supplied by the manufacturer for repl acement
purposes. If non-original parts are used, the guarantee obligations of the
manufacturer will be deemed null and void. When the polisher is being used,
the carbon brushes can be seen sparking through the rear air inlet apertures.
If the carbon brushes spark excessively, switch off the polisher immediately.
Take the polisher to a customer service workshop authorised by
the manufacturer.
Gears
NOTE
Do not loosen the screws on the gear head(2) during the warranty period.
Non-compliance will deem the guarantee obligations of the manufacturer null
and void.
Replacement of wear parts
Change Velcro pad
• Pull out the mains plug.
• Remove the polishing tool.
• Place machine on its back.
• Release and remove screw (2) with wrench (1).
• Remove worn Velcro pad (3).
• Remove contaminants from interior.
• Fit new Velcro pad and align securing holes.
• Insert screw (2) and tighten with wrench (1).
• Carry out test run. Check for imbalances and vibrations.
WORK INSTRUCTION
MAINTENANCE AND CARE
SPECIFICATIONS / ACCESSORIES
ACCESSORIES
Polishing pad, Auxiliary handle, front cover, Wrench, 1 pair carbon brush.
6. SPECIFICATIONS / ACCESSORIES5. WORK INSTRUCTIONS
7. CE DECLARATION OF CONFORMITY6. MAINTENANCE AND CARE
CE DECLARATION OF CONFORMITY
STATUS ITALIA S.r.l. as the responsible manufacturer declare that the following
STATUS machines: Polishers XPA9-125CE, XPA15-150CE, XPA21-150CED
are of series production and сonforms to the following European Directives:
The Machinery Directive 2006/42/EC, 2014/30/EU
And are manufactured in accordance with the following standards or standardised
documents: Specification(s) / Directive(s):
EN 60745-1:2009 + A11:2010, EN 60745-2-4:2009+A11:2011,
EN 55014-1:2006+A1:2009+A2:2011, EN 55014-2:1997+A1:2001+A2:2008,
EN 61000-3-2:2014, EN 61000-3-3:2013.
The technical documentation kept by the manufacturer: STATUS ITALIA S.R.L.,
via Aldo Moro, 14/A, 36060 - Pianezze (VI), ITALY
Caron Giacinto
Director
STATUS ITALIA S.R.L.
EN
11
MODEL XPA9-125CE XPA15-150CE XPA21-150CED
Tool holder Velcro Ø (mm) 125 150 150
Orbit (mm) 9 15 21
Orbit rate (OPM) 2000-6400 2000-4200 2000-4800
Power input (W) 650 900 950
Weight (kg) 2 2,6 3
Safety class II
A-weighted sound pressure level according to EN 62841 (see “Noise and vibration”):
Sound pressure level LpA dB(A) 89 84,3 87
Sound power level LWA dB(A) 100 95,3 98
Uncertainty K db 3.0
Total vibration value according to EN 62841 (see “Noise and vibration”):
Emission value ah m/s² 3,09 13,469 3,06
Uncertainty K m/s² 1.5
