ENGLISH
8
(Original instructions)
12. Depth scale
13. Bevel angle scale
14. Saw blade hex wrench
15. Spindle lock button
Assembly/Adjustment set-up
Warning: Always unplug saw from power
supply before any of the following
operations.
Adjusting the depth of cut (Fig. E
and F)
The depth of cut should be set according to
the thickness of the workpiece.
• Loosen the lever (11) to unlock the saw
shoe.
• Move the saw shoe (4) into the desired
position (Fig. E). The corresponding
depth of cut can be read from the scale
(12).
• Tighten the lever to lock the saw shoe in
place.
• Set depth adjustment of saw such that
one tooth of the blade projects below
the workpiece as shown in (Fig. F).
Adjusting the bevel angle (Fig. G)
This tool can be set to bevel angles between
0° and 45°
• Loosen the locking knob (8) to unlock
the saw shoe.
• Move the saw shoe (4) into the desired
position (Fig. G). The corresponding
bevel angle can be read from the scale
(13).
• Tighten the locking knob to lock the saw
shoe in place.
Installing the blade (Fig. H)
• Keep the spindle lock button (15)
depressed and rotate the blade until the
spindle lock engages.
• Loosen and remove the blade retaining
screw (10) by turning the hex wrench
(14) counterclockwise (Fig. H).
• Remove the outer washer (9).
• Place the saw blade (5) onto the spindle
shaft, making sure that the arrow on the
blade points in the same direction as the
arrow on the upper gaurd of the tool.
• Fit the outer washer on the spindle with
the larger flat surface against the blade.
• Insert the blade retaining screw into the
hole in the spindle.
• Securely tighten the blade retaining
screw by turning hex wrench clockwise to
tighten the blade retaining screw.
Removing the blade
• Loosen and remove the blade retaining
screw (10) by turning it counterclockwise
using the hex wrench (14).
• Remove the outer washer (9).
• Remove the saw blade (5).
Notice: To reduce the risk of serious
personal injury, read, understand and follow
all important safety warnings and
instructions prior to using tool.
Warning: To reduce the risk of serious
personal injury, read, understand and follow
all important safety warnings and
instructions prior to using tool.
General Cuts
(Important: read safety warnings
and instructions.)
Guard against kickback
With unit unplugged, follow all assembly,
adjustment and set up instructions. Make
sure lower guard operates. Select the proper
blade for the material to be cut.
• Measure and mark work for cutting.
• Support and secure work properly (See
Safety Rules and Instructions).
• Use appropriate and required safety
equipment (See Safety Rules).
• Secure and maintain work area (See
Safety Rules).
