Black & Decker JS10 [9/40] English

ENGLISH

(Original instructions)

Plunge cutting

Warning! To avoid loss of control, broken

blades or damage to the workpiece, always

use extreme caution when making plunge

cuts. It is not recommended to plunge cut

any material other than wood. Wherever

possible, drill a 3/8” (8 mm) or bigger pilot

hole in the area to be cut out and start

cutting with the blade in the pilot hole. This

will avoid the need to plunge cut.

Note: Use only blades with 7 teeth per inch

for plunge cutting.

1. To plunge cut an inside hole, clearly mark

the cutting line on the workpiece.

2. Set the bevel angle at 0° then lock the

sole plate.

3. Tilt the saw forward so it rests on the

front edge of the sole plate and in a

position so the blade will NOT touch the

workpiece when the switch is turned ON

(Fig. J).

Note: Make sure the saw blade is inside

the area to be cut.

4. Start the saw and slowly lower the blade

onto the workpiece while making sure

the front of the sole plate remains in

contact with the workpiece. Allow the

blade to cut through the wood.

5. Continue lowering the blade into the

workpiece until the sole plate rests ﬂat

on the workpiece. Continue sawing

toward the cutting line and complete the

cut as required.

Metal cutting

Many types of metal can be cut with your

jigsaw. When cutting any kind of material,

be careful not to twist or bend the blades.

Do not force the blade. If the blade chatters

or vibrates excessively, use a ﬁner tooth

blade. If the blade heats excessively, reduce

speed of cutting. If the blade teeth become

clogged when cutting soft metals such as

aluminum, use a coarser blade with fewer

teeth per inch. Clamp all work ﬁrmly and

saw as close as possible to the clamping

point to eliminate any vibration of the work

being cut.

When cutting conduit, pipe or angle iron,

clamp work in a vise if possible and saw

close to the vise. To cut thin sheet materials,

“sandwich” the material between hardboard

or plywood and clamp the layers to eliminate

material vibration and tearing. By doing this,

the material will be cut smoothly. Lay out

your pattern or cutting lines on top of the

“sandwich”.

MAINTENANCE

General

Warning! Do not at any time allow solvents

such as brake ﬂuids, gasoline,

petroleum-based products, penetrating oils,

etc. to come in contact with plastic parts.

They contain chemicals that can damage,

weaken or destroy plastic. Use a clean dry

cloth to remove dirt, dust, oil, grease, etc.

Warning! Use safety goggles when using an

air jet to blow dust out of the jigsaw. Using

this jigsaw for cutting ﬁberglass, wallboard

or plaster will result in accelerated wear due

to the abrasive nature of these materials. It is

important that you clean the jigsaw

frequently when cutting these materials.

DO NOT abuse power tools. Abusive

practices can damage the tool as well as the

workpiece.

Warning! DO NOT attempt to modify this

jigsaw or create accessories not

recommended for this jigsaw. Any such

alteration or modiﬁcation is misuse and

could result in a hazardous condition leading

to possible serious injury. It will also void the

warranty.

Your BLACK+DECKER tool has been

designed to operate over a long period of

time with a minimum of maintenance.

Continuous satisfactory operation depends

upon proper tool care and regular cleaning.

• Regularly clean the ventilation slots in

your tool using a soft brush or dry cloth.

• Regularly clean the motor housing using

a damp cloth. Do not use any abrasive or

solvent-based cleaner. Never let any

liquid get inside the tool and never

immerse any part of the tool into liquid.
