![Avaya 3645 [5/11] White paper](/views2/1006395/page5/bg5.png)
White Paper
© Copyright 2006 Avaya Corporation. All rights reserved Page 5
1.2 General WLAN environment
The Avaya wireless telephones need a correctly configured WLAN environment. This means using
proper channel allocation – the strongest Access Point (AP) should be on different channel than the
next strongest AP – and the use of a pre-installation/post-installation Site Survey to certify installation.
Depending on the planned Avaya phone type there are different requirements which should be met to
avoid disturbances in the final system (table 4).
Avaya 3631 Avaya 3641/3645
AP Recommendations
Set phone to same transmit
power setting as AP
Set phone to same transmit
power setting as AP
Minimum recommended signal
strength -70dBm
Minimum recommended signal
strength -70dBm
-60dBm minimum for high data
rate
-60dBm minimum for high data
rate
802.11e support Must support SVP prioritzation
-
A
P should be Spectralink View
certified
1
AVPP - mandatory
table 4: WLAN environment
1.3 Add on WLAN device - Avaya Voice Priority Processor
The Avaya Voice Priority Processor (AVPP) is an Ethernet LAN device that works with the AP to pro-
vide QoS on the wireless LAN. Voice packets and call signalling to and from the Avaya WTs are inter-
cepted by the AVPP and encapsulated for prioritization as they are routed to and from an IP telephony
server or gateway. The main characteristics are
• an Ethernet LAN appliance that works with the AP to provide QoS on the wireless LAN
• all packets to and from the 3641/3645 Wireless IP Telephones are sent through the Avaya Voice
Priority Processor and are encapsulated for prioritization as they are routed to and from the
3641/3645 handsets.
• AVPP also provides bandwidth admission control and aids telephones in power management
The AVPP may also be referred to as SVP (Spectralink Voice Processor). This is the same device
(hardware & software) with Spectralink logo and labels – may be found especially in older installations.
Note this device is required for the Avaya 3641/3645 handsets only.
1
Voice Interoperability for Enterprise Wireless (VIEW) Certification Program
The SpectraLink VIEW Certification Program is a partner program designed to ensure interoperability and maximum perform-
ance for enterprise Wi-Fi infrastructure products that support NetLink Wireless Telephones. See also:
http://www.spectralink.com/resources/wifi_compatibility.jsp
fig. 1: AVPP
