White Paper
© Copyright 2006 Avaya Corporation. All rights reserved Page 9
3.1.3 Avaya 3641/3645 Configuration
For the Avaya 3641/3645 handsets a correctly configured AVPP is mandatory. Refer to [2]] for con-
figuration details.
3.1.3.1 Minimum Configuration Data
For WLAN settings the following data should be entered manually via admin menue or through the
Handset Administration Tool running on a Windows PC.
• Telephony Protocol (via admin menu only, set to 033)
• ESSID
• Security Type (none/WEP/WPA/WPA2)
• Encryption Key
• Regulatory Domain (via admin menu only
2
)
• 802.11 configuration (a/b/g)
• Transmit power (recommended)
For network purposes the data below should be entered manually, through Handset Administration
Tool, or passed by DHCP.
• IP Address
• Subnet Mask
• Default Gateway IP address
• TFTP Server IP address
• AVPP Server IP address
• Call Server IP address
• Call Server Port
• OAI Gateway IP address (optional)
• Syslog Server IP address (optional)
• Time Server IP address (optional)
3.1.4 Avaya Voice Priority Processor (AVPP)
To support Avaya 3641/3645 handsets the requirements for the AVPP are
• Must be running firmware version 17x.028 or later.
• the Avaya Voice Priority Processor must be statically configured to have a permanent IP ad-
dress.
• must be on the same subnet as the Wireless Telephones
For further information on how to configure the AVPP refer to [2].
3.1.5 TFTP Server
It is strongly suggested to use the Microsoft or 3COM TFTP server, which supports a retransmission if
any error occurs.
The 3COM TFTP server is available as:
http://support.3com.com/software/utilities_for_windows_32_bit.htm
here use “3CDaemons ver. 2.0 rev.10 (3cdv2r10.zip).
2
Selects Network Config option, then Reg Domain option. Use Line button to set to proper domain
(01 for US, 02 for EU).
