GB
- 20 -
Benefi ts:
•
The drill bit is easier to control when starting
the hole and will not slide away.
•
You avoid drilling messy holes (for example
in tiles).
6.3 Preselecting the speed (Fig. 11/Item 6)
•
The speed setting ring (6) enables you to
define the maximum speed. The ON/OFF
switch (5) can only be pressed to the defined
maximum speed setting.
•
Set the speed using the setting ring (6) on the
ON/OFF switch (5).
•
Do not attempt to make this setting whilst the
drill is in use.
6.4 Clockwise/Counter-clockwise switch
(Fig. 11/Item 7)
•
Change switch position only when the drill is
at a standstill!
•
Switch the direction of the hammer drill using
the clockwise/counter-clockwise switch (7):
Direction Switch position
Clockwise (forwards and drill) Pushed in to the
right
Counter-clockwise (reverse) Pushed in to the
left
6.5 Drill / hammer drill selector switch (Fig.
12/Item 3)
Change switch position only when the drill is at a
standstill!
Drill
Drill / hammer drill selector switch (3) in the drill
position. (Position A)
Use for: Wood, metal, plastic
Hammer drill
Drill / hammer drill selector switch (3) in the ham-
mer drill position. (Position B)
Use for: Concrete, rock, masonry
6.6 Tips for working with your hammer drill
6.6.1 Drilling concrete and masonry
•
Switch the Drill/Hammer drill selector switch
(3) to position B (Hammer drill).
•
Always use carbide drill bits and a high speed
setting for drilling into masonry and concrete.
6.6.2 Drilling steel
•
Switch the drill / hammer drill selector switch
(3) to position A (drill).
•
Always use HSS drill bits (HSS = high speed
steel) and a low speed setting for drilling
steel.
•
We recommend that you lubricate the hole
with a suitable cutting fluid to prevent unne-
cessary drill bit wear.
6.6.3 Starting holes
If you wish to drill a deep hole in a hard material
(such as steel), we recommend that you start the
hole with a smaller drill bit.
6.6.4 Drilling tiles
•
To start the hole, switch the drill / hammer drill
selector switch (3) to position A (drill).
•
Switch the drill / hammer drill selector switch
(3) to position B (hammer drill) as soon as the
drill bit has passed through the tiles.
6.7 Drilling with the dust extraction system
(9)
Use the dust extraction system only for drilling
into concrete, bricks and masonry since wood
or plastic chips may block the extraction system.
Do not drill into metallic materials since hot metal
chips can damage the dust extraction system.
•
Fit the dust extraction system (10); see point
5.4.
•
Connect the dust extractor adapter (9) to the
suction hose of a suitable vacuum cleaner.
The vacuum cleaner must be suitable for
handling the substance that will be extracted.
Harmful dust must not be extracted using the
dust extraction system (10). Use on materi-
als containing asbestos is prohibited!
•
Set the required drilling depth (see point 5.2).
•
Mark the drilling position.
•
Tip: To prevent the wall being soiled, you can
mask the area around the transparent extrac-
tion opening with masking tape. Before you
use the masking tape, test whether the tape
can be removed easily from the wall again in
a place that it not easily visible.
•
Switch on the vacuum cleaner and place the
transparent cover on the front of the dust ex-
traction system (10) over the drilling point so
that the drill bit is in front of the mark. Ensure
that the transparent cover is in contact with
the workpiece or wall.
•
Press the drill bit and machine gently against
the mark whilst the ON/OFF switch (5) is still
set to off.
