5.3 Fitting the drill bit (Fig. 10)
•
Always pull the power plug before making ad-
justments to the equipment.
•
Release the depth stop as described in 5.2
and push it towards the additional handle.
In addition the dust extraction system (10)
should be removed (see 5.4). This provides
free access to the chuck (1).
•
This hammer drill is equipped with a spindle
lock (11) and a quick-change drill chuck.
•
Press the spindle lock (11) and turn the drill
chuck (1) until it engages. Keeping the spind-
le lock (11) pressed, turn the firmly closed
drill chuck (1) so that it opens. The drill chuck
opening must be large enough to take the
drill bit.
•
Select a suitable drill bit. Push the drill bit as
far as possible into the chuck opening.
•
Keeping the spindle lock (11) pressed, turn
the drill chuck (1) so that it closes. Check that
the drill bit is secure in the chuck (1).
•
Check at regular intervals that the drill bit or
tool is secure (pull the mains plug).
•
When the quick-change drill chuck (1) is open
as far as it will go (maximum drill bit opening)
and secure, press the spindle lock (11) and
turn the drill chuck (1) clockwise (viewed from
the front) until you hear a grating noise. Kee-
ping the spindle lock (11) pressed, turn the
drill chuck (1) approx. 5 mm in the opposite
direction until you hear a clicking noise. Then
turn the drill chuck (1) clockwise again to the
desired position. This function will prevent
damage to the drill chuck.
5.4 Fitting the dust extraction system
(Fig. 5-9)
The dust extraction system (10) is fi tted on the
additional handle (8). It can also be used in com-
bination with the depth stop (2). This prevents the
work area becoming very dirty.
•
Release the cover (A) and the sealing cap (B)
by turning the additional handle (8). Several
drill bits can be stored in the sealing cap (B)
to save space (Fig. 5-6).
•
Screw the dust extractor adapter (9) on to the
additional handle (8) from underneath.
•
Now place the dust extraction system (10) on
to the additional handle (8) as shown in Fig.
7 – 8 and secure it by turning it.
•
Important. There are detents on the cover (A)
and the dust extraction system (10) which
must be engaged in the corresponding reces-
ses on the additional handle (8) before the
cover (A) or dust extraction system (10) can
be turned and locked.
•
Remove the dust extraction system (10) by
following the above in reverse.
•
Fit the additional handle (8) on the machine
as described in 5.1. Please note that the
additional handle (8) must be fitted to the left-
hand side of the machine if the dust extrac-
tion system (10) is also fitted (Fig. 9).
•
The dust extraction system (10) can be fitted
to the machine even if the additional handle
(8) is fitted.
•
If the dust extraction system (10) is not re-
quired, the cover (A) and the sealing cap (B)
must be fitted to the additional handle (8).
6. Operation
6.1 ON/OFF switch (Fig. 11/Item 5)
•
First fit a suitable drill bit into the tool (see
5.3).
•
Connect the mains plug to a suitable socket.
•
Position the drill in the position you wish to
drill.
To switch on:
Press the ON/OFF switch (5)
Continuous operation:
Secure the ON/OFF switch (5) with the locking
button (4).
Important! Locking is possible only in clockwise
rotation.
To switch off :
Press the ON/OFF switch (5) briefl y.
6.2 Adjusting the speed (Fig. 11/Item 5)
•
You can infinitely vary the speed whilst using
the tool.
•
Select the speed by applying a greater or les-
ser pressure to the ON/OFF switch (5).
•
Select the correct speed: The most suitable
speed depends on the workpiece, the type of
use and the drill bit used.
•
Low pressure on the ON/OFF switch (5): Lo-
wer speed (suitable for: small screws and soft
materials)
•
Greater pressure on the ON/OFF switch (5):
Higher speed (suitable for large/long screws
and hard materials)
Tip: Start drilling holes at low speed. Then increa-
se the speed in stages.
