4
English
SPECIFICATIONS
Model RB40SA RB40VA
Voltage (by areas) * (110 V, 220 V, 230 V, 240 V)
Power Input 550 W*
No-load speed 16000 min
-1
0 – 16000 min
-1
Air pressure 5.5 kPa 0 – 5.5 kPa
Air volume 3.8 m
3
/ min 0 – 3.8 m
3
/ min
Weight
(without cord)
1.7 kg
* Be sure to check the nameplate on product as it is subject
to change by areas.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Attachment of a Nozzle 1 71
Attachment of a Dust Box 2 71
Dust-collecting work 3 71
Adjustment of the amount of winds 4 71
Inspecting the carbon brushes 5 72
Selecting accessories ― 73
MAINTENANCE AND INSPECTION
1. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
2. Inspecting the carbon brushes (Fig. 5)
The motor employs carbon brushes which are
consumable parts. Since an excessively worn carbon
brush can result in motor trouble, replace the carbon
brushes with new ones having the same carbon brush
No. ⓐ shown in the fi gure when it becomes worn to or
near the “wear limit” ⓑ. In addition, always keep carbon
brushes clean and ensue that they slide freely within the
brush holders.
3. Replacing carbon brushes (Fig. 5)
Disassemble the brush cap with a slotted-head
screwdriver. The carbon brushes can then be easily
removed.
4. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
CAUTION
In the operation and maintenance of power tools, the safety
regulations and standards prescribed in each country must
be observed.
GUARANTEE
We guarantee HiKOKI Power Tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
IMPORTANT
Correct connection of the plug
The wires of the main lead are coloured in accordance
with the following code:
Blue: — Neutral
Brown: — Live
As the colours of the wires in the main lead of this tool may
not correspond with the coloured markings identifying the
terminals in your plug proceed as follows:
The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black. The wire
coloured brown must be connected to the terminal marked
with the letter L or coloured red. Neither core must be
connected to the earth terminal.
NOTE
This requirement is provided according to BRITISH
STANDARD 2769: 1984.
Therefore, the letter code and colour code may not be
applicable to other markets except The United Kingdom.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
Measured A-weighted sound power level: 94 dB (A)
Measured A-weighted sound pressure level: 83 dB (A)
Uncertainty K: 3 dB (A).
Wear hearing protection.
Vibration total values (triax vector sum) determined
according to EN60745.
Vibration emission value
a
h
= 4.1 m/s
2
Uncertainty K = 1.5 m/s
2
The declared vibration total value has been measured in
accordance with a standard test method and may be used
for comparing one tool with another.
It may also be used in a preliminary assessment of exposure.
WARNING
○ The vibration emission during actual use of the power
tool can diff er from the declared total value depending in
the ways in which the tool is used.
○ Identify safety measures to protect the operator that
are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the
trigger time).
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
