Preparing for Printing

If Bidirectional Communication Is Disabled

Set up option settings when bidirectional communications are disabled.

Important

❒ Manage Printers permission is required to change the printer properties in

the [Printers] folder. Log on as an Administrators or Power Users group mem-

ber.

❒ Make sure that [Enable bidirectional support] is selected on the [Ports] tab in the

printer properties dialog box. Printing is possible only if this check box is se-

lected.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

When using Windows XP, and Windows Server 2003/2003 R2, click [Printers

and Faxes] on the [Start] menu. The [Printers and Faxes] window appears.

When using Windows Vista, click [Control Panel] on the [Start] menu, and then

click [Printer]. The [Printer] window appears.

B Click the icon of the printer you want to use.

C On the [File] menu, click [Properties].

D Click the [Accessories] tab.

If you are using the PostScript 3 printer driver, click the [Device Settings] tab.

E Select options installed from the [Options] area, and then make the neces-

sary settings.

F Select the total amount of the memory in [Total Memory:], when the optional

SDRAM module is added.

G Under [Paper Size Settings], click and highlight the tray to be used, select the

appropriate size , and then click [Update].

H Click [OK] to close the printer properties dialog box.
