6
ENGLISH
FR66P ROUTER
(Ilustrations in page 32)
Important
Read these OPERATING INSTRUCTIONS
and the attached GENERAL SAFETY
INSTRUCTIONS LEAFLET carefully before
using the machine. Make sure you have
understood them before operating the
machine for the first time.
Keep both sets of instructions for any
future queries.
1. TECHNICAL DATA
Universal motor.........................................50/60 Hz
Input power................................................1,300 W
No-load speed.......................................26,000/min
Standard chuck diameter................................8 mm
Routing depth............................................0-60 mm
Revolving depth
gauge.......................6-position depth adjustment
Weight...........................................................3.8 Kg
Weighted equivalent continuous
acoustic pressure level A............................................87 dBA
Acoustic power level A.............................................98 dBA
Uncertainty............................................................K = 3 dBA
Wear ear protection!
Vibration total values......................................a
h
: <2.5 m/s
2
Uncertainty...........................................................K: 1.5 m/s
2
2. OPERATION RANGE
The router is an electric appliance used for routing wood
and plastics. It is also very convenient for trimming ed-
ges, cutting out of knots, copy cutting, rebate cutting,
making of frames and engraving.
Together with parallel guide, template followers, com-
passes and profile cutters, it is an exceedingly useful
appliance.
3. SAFETY INSTRUCTIONS FOR
MACHINE OPERATION
Before using the machine carefully read
the GENERAL SAFETY INSTRUCTIONS
LEAFLET, which is included in the machine
documentation.
- When changing the tools or performing any other
operation close to the cutting head, remove hand from
the switch lever and disconnect from the mains.
- Use safety goggles when working with the router.
- Always guide the router with both hands using the two
knobs J (Fig. 1), with stop lever B (Fig. 1) within easy reach.
- Following completion of a job, disconnect the motor
and release the base before leaving the router.
- Always place the router on the base, on a flat, clean
surface.
- Always use the lever of the main switch to turn the
router on.
- Ensure that the router cannot accidentally fall over.
- Use only bits of diameter suitable for the chuck to be
used, and adapted to the router speed.
- The specifications of the bits of the VIRUTEX range are
especially adapted to the performance of this router.
Use preferably bits from the extensive VIRUTEX range,
or only bits whose characteristics conform to the said
specifications.
4. STANDARD EQUIPMENT
You will find the following items inside the box:
- Surface router FR66P
- Size 26 service key
- Template guide diameter 19 for 26 mm dovetailing
- Lateral fence unit
- Aspiration connector
- Instruction manual and other documentation
5. STARTING UP THE MACHINE
Cut-out box A (Fig. 1) is equipped with lever B (Fig. 1),
which can be pressed with a finger. This enables the
user to start it up or stop it with no need to move his
hand from knob. To do this, activate the switch's lateral
stop C (Fig. 1) and, without releasing it, push forward
lever B. Stop C prevents the machine from starting up
accidentally.
6. ASSEMBLY OF THE CUTTING TOOLS
Assemble cutting tool D (Fig. 2, 3) in chuck E (Fig. 2),
block the axis by pressing brace F (Fig. 3) and insert
wedge G (Fig. 3) to lock the fastening in place. Tighten
nut H (Fig. 2, 3) with the service key I (Fig. 3).
Avoid leaving the machine with no tools
installed, since the chuck could be over-
tightened and damage the shaft.
7. BLOCKING OF THE BASE
The base can be locked in any position using knob J (Fig.
1). When knob is loosened, the base will automatically
return to its highest position due to the action of the
